9-36 Setting the SEL-351P Recloser Control Date Code 990430
SEL-351P Manual Técnico
Row
Bit
Definition
Primary
Application
FSA A-phase fault identification logic output used in
A-phase targeting (see Table 5.1)
Control
FSB B-phase fault identification logic output used in
B-phase targeting (see Table 5.1)
FSC C-phase fault identification logic output used in
C-phase targeting (see Table 5.1)
34 BCW BCWA + BCWB + BCWC Indication
50P32 Three-phase overcurrent threshold exceeded (see
Figure 4.14)
Testing
NOBATT
Battery is either not present or failed (see Battery
System Monitor in Section 8)
Indication
59VA Channel VA voltage window element (channel VA
voltage between threshold settings 25VLO and
25VHI; see Figure 3.24)
TRGTR Target Reset. TRGTR pulses to logical 1 for one
processing interval when either the TARGET
RESET Pushbutton is pushed or the TAR R (Target
Reset) serial port command is executed (see Figures
5.1 and 5.17)
Control
52A Circuit breaker status (asserts to logical 1 when
recloser is closed; see Figure 6.1)
Indication
COMMT Communication Scheme Trip (see Figure 5.1) Tripping
CHRGG
Battery is Charging (see Battery System Monitor in
Section 8)
Indication
35 SG1 Setting group 1 active (see Table 7.3) Indication
SG2 Setting group 2 active (see Table 7.3)
SG3 Setting group 3 active (see Table 7.3)
SG4 Setting group 4 active (see Table 7.3)
SG5 Setting group 5 active (see Table 7.3)
SG6 Setting group 6 active (see Table 7.3)
ZLOUT
ZLIN
Load enchroachment “load out” element (see
Figure 4.2)
Load enchroachment “load in” element (see
Figure 4.2)
Special phase
overcurrent
element control
36 ZLOAD ZLOUT + ZLIN (see Figure 4.2)
