S
ETTINGS
S
HEET Page
18
of 23
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL Date
G
LOBAL
S
ETTINGS
(S
ERIAL
P
ORT
C
OMMAND
SET G
AND
F
RONT
P
ANEL
)
Date Code 990215
Settings Group Change Delay (see Multiple Setting Groups in Section 7)
Group change delay (0.00-16000.00 cycles in 0.25-cycle steps) TGR =
Power System Configuration and Date Format (see Settings Explanations in Section 9)
Nominal frequency (50 Hz, 60 Hz) NFREQ =
Phase rotation (ABC, ACB) PHROT =
Date format (MDY, YMD) DATE_F =
Front-Panel Display Time-Out (see Section 11)
Front-panel display time-out (0-30 minutes in 1-minute steps) FP_TO =
[If FP_TO = 0, no time-out occurs and display remains on last display screen (e.g., continually display
metering)]
Event Report Parameters (see Section 12)
Length of event report (15, 30 cycles) LER =
Length of prefault in event report (1 to LER-1 cycles in 1-cycle steps) PRE =
Optoisolated Input Timers (see Figure 7.1)
Input IN101 debounce time (0.00-1.00 cycles in 0.25-cycle steps) IN101D =
Input IN102 debounce time (0.00-1.00 cycles in 0.25-cycle steps) IN102D =
Input IN103 debounce time (0.00-1.00 cycles in 0.25-cycle steps) IN103D =
Input IN104 debounce time (0.00-1.00 cycles in 0.25-cycle steps) IN104D =
Input IN105 debounce time (0.00-1.00 cycles in 0.25-cycle steps) IN105D =
Input IN106 debounce time (0.00-1.00 cycles in 0.25-cycle steps) IN106D =
Breaker Monitor Settings (see Breaker/Recloser Contact Wear Monitor in Section 8)
Breaker monitor enable (Y, N) EBMON =
(Make the following settings if preceding enable setting EBMON = Y)
Close /Open set point 1 - max. (0-65000 operations) COSP1 =
Close /Open set point 2 - mid. (0-65000 operations) COSP2 =
Close /Open set point 3 - min. (0-65000 operations) COSP3 =
kA Interrupted set point 1 - min. (0.10-999.00 kA primary in 0.01 kA
steps)
KASP1 =
kA Interrupted set point 2 - mid. (0.10-999.00 kA primary in 0.01 kA
steps)
KASP2 =
kA Interrupted set point 3 - max. (0.10-999.00 kA primary in 0.01 kA
steps)
KASP3 =
