S
ETTINGS
S
HEET Page
19
of 23
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL Date
G
LOBAL
S
ETTINGS
(S
ERIAL
P
ORT
C
OMMAND
SET G
AND
F
RONT
P
ANEL
)
Date Code 990215
Trip Latch LEDs Settings (see Figures 1.51 through 1.54)
Trip latch LED11 (Y,N) LED11L =
Trip latch LED12 (Y,N) LED12L =
Trip latch LED13 (Y,N) LED13L =
Trip latch LED14 (Y,N) LED14L =
Trip latch LED15 (Y,N) LED15L =
Trip latch LED16 (Y,N) LED16L =
Trip latch LED17 (Y,N) LED17L =
Trip latch LED18 (Y,N) LED18L =
Trip latch LED19 (Y,N) LED19L =
Trip latch LED20 (Y,N) LED20L =
Trip latch LED24 (Y,N) LED24L =
Trip latch LED25 (Y,N) LED25L =
Reset trip-latched LEDs when recloser closes (Y,N) RSTLED =
Other Global Settings
CLOSE operator control time delay (0-3600 cyc) (see Figure 1.39) PB8D =
TRIP operator control time delay (0-3600 cyc) (see Figure 1.40) PB9D =
True three-phase voltage connected (Y,N) (see Figure 4.1 in Section 4
and A, B, C target LED discussion at end of Section 5)
3PVOLT =
# of EZ settings groups enabled (0-6) [see SET EZ and SET FZ
Commands (Change EZ Settings) in Section 10]
EZGRPS =
Battery, 12 V Power, and Wake-Up Port Settings (see Battery System Monitor in
Section 8)
Battery Amp-hours (6.5-20) AMPHR =
% Battery capacity for sleep (0-100) SLPCAP =
Turn on the 12 V power (Y,N) ON12V =
(Set the following 12VSLP setting when preceding setting ON12V
= Y)
Keep the 12 V power on while asleep (Y,N) 12VSLP =
Wake-up port baud rate (1200-38400) ABAUD =
Wake-up message (4 characters: 0-9, A-Z, -, /, ., space)
CHWAKE=
SF6 low pressure warning threshold (0.9-2.0 atmospheres) SF6PRS
