12-20 Standard Event Reports and SER Date Code 990215
SEL-351P Manual Técnico
Column
Heading
Corresponding Elements
(Relay Word Bits)
Symbol
Definition
TMB A 56 TMB5A, TMB6A 5 Transmit Mirrored Bit 5 channel A
asserted and Transmit Mirrored
Bit 6 channel A deasserted.
6 Transmit Mirrored Bit 5 channel A
deasserted and Transmit Mirrored
Bit 6 channel A asserted.
b Transmit Mirrored Bit 5 channel A
asserted and Transmit Mirrored
Bit 6 channel A asserted.
TMB A 78 TMB7A, TMB8A 7 Transmit Mirrored Bit 7 channel A
asserted and Transmit Mirrored
Bit 8 channel A deasserted.
8 Transmit Mirrored Bit 7 channel A
deasserted and Transmit Mirrored
Bit 8 channel A asserted.
b Transmit Mirrored Bit 7 channel A
asserted and Transmit Mirrored
Bit 8 channel A asserted.
RMB A 12 RMB1A, RMB2A 1 Receive Mirrored Bit 1 channel A
asserted and Receive Mirrored Bit
2 channel A deasserted.
2 Receive Mirrored Bit 1 channel A
deasserted and Receive Mirrored
Bit 2 channel A asserted.
b Receive Mirrored Bit 1 channel A
asserted and Receive Mirrored Bit
2 channel A asserted.
RMB A 34 RMB3A, RMB4A 3 Receive Mirrored Bit 3 channel A
asserted and Receive Mirrored Bit
4 channel A deasserted.
4 Receive Mirrored Bit 3 channel A
deasserted and Receive Mirrored
Bit 4 channel A asserted.
b Receive Mirrored Bit 3 channel A
asserted and Receive Mirrored Bit
4 channel A asserted.
