Date Code 990215 Standard Event Reports and SER 12-21
SEL-351P Manual Técnico
Column
Heading
Corresponding Elements
(Relay Word Bits)
Symbol
Definition
RMB A 56 RMB5A, RMB6A 5 Receive Mirrored Bit 5 channel A
asserted and Receive Mirrored Bit
6 channel A deasserted.
6 Receive Mirrored Bit 5 channel A
deasserted and Receive Mirrored
Bit 6 channel A asserted.
b Receive Mirrored Bit 5 channel A
asserted and Receive Mirrored Bit
6 channel A asserted.
RMB A 78 RMB7A, RMB8A 7 Receive Mirrored Bit 7 channel A
asserted and Receive Mirrored Bit
8 channel A deasserted.
8 Receive Mirrored Bit 7 channel A
deasserted and Receive Mirrored
Bit 8 channel A asserted.
b Receive Mirrored Bit 7 channel A
asserted and Receive Mirrored Bit
8 channel A asserted.
ROK ROKA, ROKB A Receive channel A OK element
asserted and Receive channel B
OK element deasserted.
B Receive channel A OK element
deasserted and Receive channel B
OK element asserted.
b Receive channel A OK element
asserted and Receive channel B
OK element asserted.
RBAD RBADA, RBADB A Receive channel A BAD for
certain time element asserted and
Receive channel B BAD for
certain time element deasserted.
B Receive channel A BAD for
certain time element deasserted
and Receive channel B BAD for
certain time element asserted.
b Receive channel A BAD for
certain time element asserted and
Receive channel B BAD for
certain time element asserted.
CBAD CBADA, CBADB A
Channel A communications
availability BAD element asserted
and Channel B communications
availability BAD element
deasserted.
