12-22 Standard Event Reports and SER Date Code 990215
SEL-351P Manual Técnico
Column
Heading
Corresponding Elements
(Relay Word Bits)
Symbol
Definition
B
Channel A communications
availability BAD element
deasserted and Channel B
communications availability BAD
element asserted.
b
Channel A communications
availability BAD element asserted
and Channel B communications
availability BAD element asserted.
PB1 PB1 (see Figure 1.35) *
Ground Enabled pushbutton output
PB2 PB2 *
Reclose Enabled pushbutton output
PB3 PB3 *
Remote Enabled pushbutton output
PB4 PB4 *
Alternate Settings pushbutton
output
PB5 PB5 *
Lock pushbutton output
PB6 PB6 (see Figure 1.36) *
Aux. 1 pushbutton output
PB7 PB7 *
Aux. 2 pushbutton output
PB8 PB8 *
Close pushbutton output
PB9 PB9 *
Trip pushbutton output
**Output contacts can be A or B type contacts (see Table 2.1 and Figure 7.26).
S
EQUENTIAL
E
VENTS
R
ECORDER
(SER) R
EPORT
See Figure SECTION 12: .5 for an example SER report.
SER Triggering
The control triggers (generates) an entry in the SER report for a change of state of any one of the
elements listed in the SER1, SER2, and SER3 trigger settings. The factory default settings are:
SER1 = TRIP 51P1T 51P2T 51G1T 51G2T 51N1T 51N2T 67P2T 67G2T 67N2T
67N3T 81D1T PB9 67P1 67G1 67N1
SER2 = CLOSE 52A CF 79CY 79LO 79RS SH0 SH1 SH2 SH3 SH4 PB8 59A1
SER3 = TOSLP BCBOK DTFAIL
The elements are Relay Word bits referenced in Table 9.3. The control monitors each element in
the SER lists every 1/4 cycle. If an element changes state, the control time-tags the changes in
the SER. For example, setting SER1 contains:
• Time-overcurrent element trips (51P1T, 51P2T, 51G1T, 51G2T, 51N1T, and 51N2T)
• Definite-time overcurrent element trips (67P2T, 67G2T, 67N2T, 67N3T)
• Definite-time frequency element (81D1T)
• Manual TRIP from front-panel pushbutton (PB9)
