Date Code 990215 Standard Event Reports and SER 12-33
SEL-351P Manual Técnico
The present sample (IA = 824 A) is a real RMS current value that relates to the phasor RMS
current value:
991 A * cos(-33.7°) = 824 A
E
XAMPLE
S
EQUENTIAL
E
VENTS
R
ECORDER
(SER) R
EPORT
The following example sequential events recorder (SER) report in Figure SECTION 12: .5 also
corresponds to the example standard 15-cycle event report in
Figure SECTION 12: .2.
RECLOSER R1 Date: 06/01/98 Time: 12:24:25.371
FEEDER 2101
FID=SEL-351P-R100-V0-D990213 CID=C867 BCBFID=R103
# DATE TIME ELEMENT STATE
24 06/01/98 12:00:00.000 Relay newly powered up or settings changed
23 06/01/98 12:23:26.915 CLOSE Asserted
22 06/01/98 12:23:26.915 PB8 Asserted
21 06/01/98 12:23:26.920 PB8 Deasserted
20 06/01/98 12:23:26.961 CLOSE Deasserted
19 06/01/98 12:23:26.965 52A Asserted
18 06/01/98 12:23:36.971 79LO Deasserted
17 06/01/98 12:23:36.971 79RS Asserted
16 06/01/98 12:23:36.975 SH3 Deasserted
15 06/01/98 12:23:36.975 SH0 Asserted
14 06/01/98 12:23:52.527 51G1T Asserted
13 06/01/98 12:23:52.527 79CY Asserted
12 06/01/98 12:23:52.527 79RS Deasserted
11 06/01/98 12:23:52.527 TRIP Asserted
10 06/01/98 12:23:52.535 51P1T Asserted
9 06/01/98 12:23:52.581 52A Deasserted
8 06/01/98 12:23:52.598 51P1T Deasserted
7 06/01/98 12:23:52.602 51G1T Deasserted
6 06/01/98 12:23:52.602 TRIP Deasserted
5 06/01/98 12:23:57.598 CLOSE Asserted
4 06/01/98 12:23:57.598 SH1 Asserted
3 06/01/98 12:23:57.598 SH0 Deasserted
2 06/01/98 12:23:57.721 CLOSE Deasserted
1 06/01/98 12:23:57.725 52A Asserted
Figure SECTION 12: .5: Example Sequential Events Recorder (SER) Event Report
The SER event report rows in
Figure SECTION 12: .5 are explained in the following text,
numbered in correspondence to the # column. The circled, numbered comments in
Figure
SECTION 12: .2 also correspond to the # column numbers in
Figure SECTION 12: .5. The
SER event report in
Figure SECTION 12: .5 contains records of events that occurred before and
after the standard event report in
Figure SECTION 12: .2.
