64 SEL-351P Quick-Start Installation and User's Guide (Portuguese)
EZ S
ETTINGS
S
HEET
Page 2 of 4
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL
Date
Settings Groups 1 (Main) and 2 (Alternate)
EZ Settings (SET EZ n command; n = 1, 2):
Range:
Incr.:
Settings:
Reset time for auto reclose 0-999999.00 cycles 0.25
Reset time from lockout 0-999999.00 cycles 0.25
Close power wait time 0-16000.00 cycles 0.25
Complex fast curve - phase Y/N --
Const. time adder - phase fast curve 0-60.00 cycles 0.25
Vert. multiplier - phase fast curve 0.10-2.00 0.01
Min. response - phase fast curve 0-60.00 cycles 0.25
Complex fast curve - ground Y/N --
Const. time adder - ground fast curve 0-60.00 cycles 0.25
Vert. multiplier - ground fast curve 0.10-2.00 0.01
Min. response - ground fast curve 0-60.00 cycles 0.25
Complex delay curve - phase Y/N --
Const. time adder - phase delay curve 0-60.00 cycles 0.25
Vert. multiplier - phase delay curve 0.10-2.00 0.01
Min. response - phase delay curve 0-60.00 cycles 0.25
Complex delay curve - ground Y/N --
Const. time adder - ground delay curve 0-60.00 cycles 0.25
Vert. multiplier - ground delay curve 0.10-2.00 0.01
Min. response - ground delay curve 0-60.00 cycles 0.25
High current trip - phase Y/N --
High current trip - phase (range given for
CT Ratio = 200.0)
1.00-(4000/Min. trip - phase)
multiples of Min. trip - phase
0.01
Time delay - phase high current trip 0-16000.00 cycles 0.25
Activate high current trip - phase OFF, 1-5 1
High current trip - ground Y/N --
High current trip - ground (range given for
CT Ratio = 200.0)
1.00-(4000/Min. trip - ground)
multiples of Min. trip - ground
0.01
Time delay - ground high current trip 0-16000.00 cycles 0.25
Activate high current trip - ground OFF, 1-5 1
High current lockout - phase Y/N --
High current lockout - phase (range given
for CT Ratio = 200.0)
1.00-(4000/Min. trip - phase)
multiples of Min. trip - phase
0.01
Activate high current lockout - phase OFF, 1-5 1
