SEL-351P Quick-Start Installation and User's Guide (Portuguese) 65
EZ S
ETTINGS
S
HEET
Page 3 of 4
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL
Date
Settings Groups 1 (Main) and 2 (Alternate)
EZ Settings (SET EZ n command; n = 1, 2):
Range:
Incr.:
Settings:
High current lockout - ground Y/N --
High current lockout - ground (range given
for CT Ratio = 200.0)
1.00-(4000/Min. trip - ground)
multiples of Min. trip - ground
0.01
Activate high current lockout - ground OFF, 1-5 1
Cold load pickup scheme Y/N --
Cold load pickup - phase (range given for
CT Ratio = 200.0)
1.00-(4000/Min. trip - phase)
multiples of Min. trip - phase
0.01
Cold load pickup - ground (range given for
CT Ratio = 200.0)
1.00-(4000/Min. trip - ground)
multiples of Min. trip - ground
0.01
Loss of load diversity time 0-999999.00 cycles 0.25
Restore min. trips - time limit OFF, 0-999999.00 cycles 0.25
Restore min. trip - phase Y/N --
Restore min. trip - ground Y/N --
Restore min. trip - SEF Y/N --
Sequence coordination Y/N --
Ground trip precedence Y/N --
Underfrequency loadshedding Y/N --
Underfrequency pickup OFF, 40.10-65.00 Hz 0.01
Underfrequency time delay 2-16000.00 cycles 0.25
Demand meter time constant 5, 10, 15, 30, 60 minutes --
Global EZ Settings (SET FZ command):
System Frequency 50, 60 Hz --
Phase Rotation ABC, ACB --
Recloser Wear Monitor AUTO, Y, N --
Interrupt rating 6000, 8000, 12000 A pri. --
Reset trip-latched LEDs when recloser closes Y/N --
True three-phase voltage connected Y/N --
Battery Amp-hours 6.5-20.0 Amp-hours 0.1
% Battery capacity for sleep 0-100% 1
Turn on the 12 V power Y/N --
Keep the 12 V power on while asleep Y/N --
SF6 low pressure warning threshold 0.9 - 2.0 atmospheres 0.1
