4.2 Electrode Identification and Colour Code
The electrode colour codes in the following sections correspond to Code 1 (IEC) for
the graphics and to Code 2 (AHA) in the tables
IEC AHA
IEC label Colour AHA label Colour
R Red RA White
Limb L Yellow LA Black
F Green LL Red
C1 White/red V1 Brown/red
Chest C2 White/yellow V2 Brown/yellow
according C3 White/green V3 Brown/green
Wilson C4 White/brown V4 Brown/blue
C5 White/black V5 Brown/orange
C6 White/purple V6 Brown/purple
Neutral N Black RL Green
The patient cable (type IEC or AHA) is set in the menu Lead & Cable, see chapter
10.2.1.
