Seca CT8000P-2 - Resting ECG

10 General and System Settings
10.3 Menu Reports
Page 76
CT8000P-2
Art. no.: 2.511407 Rev.: a
10.3.3 Resting ECG
Saved ECGs can be displayed with different settings at any time.
• Patient data is always printed.
• The order listed below can vary.
•Select (), activate/deactivate with OK or with function key , sort with keys
Up/Down and Average/Rhythm amplitude 5/10/20 mm/mV.
Menu Description / selection
Lead group
• Display of the leads listed below (12 or 9 leads).
12 Lead
Select (with key OK or Activate) and define the order (function keys
Up/Down) of the following print formats:
• Rhythm 10s, 25 mm/s, 2p (pages)
• Measurements
• Averages Grid, 25/25 mm/s
• Averages Grid, 50/25 mm/s
• Averages Wide, 50/25 mm/s
• Panorama, 25 mm/s
• Rhythms 10s, 25 mm/s
• Rhythms 5s, 25 mm/s
• Rhythms 5s, 50 mm/s, 2p
• Rhythms Grid, 25 mm/s
9 Lead
• Rhythms 10s, 25 mm/s, 2p
• Measurements
• Averages Grid, 50/25 mm/s
• Averages Wide, 50/25 mm/s
• Rhythms 5s, 25 mm/s
• Rhythms 5s, 50 mm/s, 2p
Activate
Up
Down
Rhythm
5mm/mV
Average
10 mm/mV
Lead group
Rhythm 10s, 25 mm/s, 2p (pages)
Averages Grid, 25/25 mm/s
Average Amplitude: 10 mm/mV
Rhythm Amplitude: 5 mm/mV
Rhythm Amplitude: 5 mm/mV
12 Lead
