5.5 Changing the ECG display
5.5.1 Display
Leads  The following presentation can be selected in Menu > Settings > ECG > Leads
& cable:
The Standard and Cabrera lead sequences are as follows:
The lead group is selected in the ECG settings (see Page 73).
The factory setting for the Default lead configuration is Standard 12 lead. The
following settings can be made:
• Standard 12-lead
• Standard C4r
• Balanced
• Left Posterior
• Nebh (chest)
• Pediatric
• Right Precordials
Additional settings for the preview
and review
See section 10.4 Menu Layouts, page 78
The ECG preview is optimised for one or two columns with 6 leads each, or for 3
columns with 4 leads each. The amplitude and speed can be set to 5, 10 or 20 mm/
mV, and to 12,5, 25 or 50 mm/s. The ECG preview for electrode hook-up cannot be
changed.
Lead sequence Lead group 1 Lead group 2
Standard I, II, III, aVR, aVL, aVF V1, V2, V3, V4, V5, V6
Cabrera aVL, I, -aVR, II, aVF, III V1, V2, V3, V4, V5, V6
