Seca CT8000P-2 - Rhythm ECG; Exercise ECG

Page 77
Art. no.: 2.511407 Rev.: a
General and System Settings 10
User guide Menu Reports 10.3
CT8000P-2
10.3.4 Rhythm ECG
Saved ECGs can be displayed with different settings at any time.
10.3.5 Exercise ECG
Saved ECGs can be displayed with different settings at any time.
• The order listed below can vary.
•Select (), activate/deactivate with OK or with function key , sort with keys
Up/Down and Average/Rhythm amplitude 2.5/5/10 mm/mV
:
Activate
Up
Down
Rhythm
5 mm/mV
Parameter Description / selection
Rhythm
Continuous, 25 mm/s, 2:00 min
Continuous, 12,5 mm/s, 5.20 min
Continuous, 6,25 mm/s, 10.40 min
Rhythm 10s/ p (page)
Rhythm 20s/ p (page)
Rhythm summary
• The order listed below can vary.
•Select (), activate/deactivate with OK or with function key , sort with keys
Up/Down and Rhythm amplitude 5/10/20 mm/mV.
Menu Description / selection
Exercise ECG
• Summary
•ST table
• Event list 40/page
• Averages 5/page
• Averages compact
• ST trend
• Step rhythms 10s, 25 mm/s, 1p (1 page)
• Step rhythms 5s, 25 mm/s
• Step rhythms 5s, 50 mm/s 2p (2 pages)
Step print
At the end of each step, a step printout is generated. If the steps are
longer than 2 minutes, or if a step is held, a printout is generated every
2 minutes.
None, step print 5s, 25 mm/s, step print 5s, 50 mm/s, 2 pages, step
print 1x12, 25 mm/s.
Activate
Up
Down
Rhythm
5 mm/mV
