Page 41
Art. no.: 2.511407 Rev.: a
Resting ECG 5
User guide Lead sequence/lead view 4.12
CT8000P-2
5 Resting ECG
After heavy artefacts or lead off, the displayed heart rate may not be reliable.
The safety notes at the beginning of this user guide must be read and fully
understood before taking an ECG recording.
The CT8000P-2 device is CF classified . The patient connection is fully
isolated. During the ECG recording, ensure that neither the patient nor the
leading parts of the patient connection nor the electrodes (including the neutral
electrode) come in contact with other persons or conductive objects, even when
these are earthed.
Do not operate the unit if the earth connection is suspect or if the mains lead is
damaged or suspected of being damaged.
If an external electronic device is connected to the CT8000P-2, use the potential
equalisation stud for earth protection.
If another format than the default format is set for the automatic printout, the printout
can differ from the format displayed on the screen.
The ECG display can be modified with regard to lead sequence (Standard or
Cabrera), lead configuration, amplitude, speed and filter. For the preview, the
following parameters can be freely programmed (before start of the recording):
• Amplitude
• Speed
•Filter
• Lead configuration
• Pacemaker detection On/OFF
Saved recordings can be displayed and printed in another format at any time.
For further information on how to define the format, see Page 75.
