10 General and System Settings
10.4 Menu Layouts
Page 80
CT8000P-2
Art. no.: 2.511407 Rev.: a
10.4.2 Exercise ECG
Preview
Review
Menu Parameter Description
Preview
Preview view order Select whether Hookup or Recorder is shown at the top.
12-lead layout 2x6 / 4x3/ 1x6
Amplitude 5/10 /20 mm/mV
Speed 12.5/25/50 mm/s
These settings apply to current exercise ECG recordings and recordings from the
memory. Therefore, saved ECGs can be displayed with different settings at any time.
Menu Parameter Description
Rhythm ECG
Review
View selection and order
Select (with key OK or Activate) and define the order (function
keys Up/Down) of the following views:
•Trend
• Step table
• Results
• Event list
Default lead for 12-lead I/ II / III / aVR / aVL / aVF / V1 / V2 / V3 / V4 / V5 / V6 / -aVR
