SICK MCS100E User Manual

Utility programs and protocols
130 MCS100E Operating Instructions 8009504/V YWA7/V3-1/2018-01 © SICK AG
Subject to change without notice
0170 0170 U16 Result 50
0171 0171 U16 Result 51
0172 0172 U16 Result 52
0173 0173 U16 Result 53
0174 0174 U16 Result 54
0175 0175 U16 Result 55
0176 0176 U16 Result 56
0177 0177 U16 Result 57
0178 0178 U16 Result 58
0179 0179 U16 Result 59
0180 0180 U16 Result 60
0181 0181 U16 Result 61
0182 0182 U16 Result 62
0183 0183 U16 Result 63
0184 0184 U16 Result 64
0185 0200 Reserved
Start End Data Type Description Remarks
Component data block
Component 1 Values:register offset Compon = 200
0201 0202 U32 Date Stamp last Calibration
0203 0204 U32 Time Stamp last Calibration
0205 0206 Float Actual Concentration PKnz
0207 0208 Float mExt add. and mult. correction PExtCor
0209 0210 Float mExt additive correction PExtAdd
0211 0212 Float mExt with ZERO-correction PExtRawN
0213 0214 Float mExt without ZERO-correction PExtRaw
0215 0216 Float Reference Signal [0..100%] PRef
0217 0218 Float Measure Signal [0..100%] PMes
0219 0220 Float Calibration Value PCalV
0221 0222 Float First Calibration Value PCal1
0223 0224 Float Last Calibration Value PCalLast
0225 0226 Float Actual Calibration Value PCalAct
0227 0228 Float First Zero Value PNul1
0229 0230 Float Last Zero Value PNulLast
0231 0232 Float Actual Zero Value PNulAct
0233 0234 Float Extra Offset [Absorb] Poffset
0235 0236 Float Extra Factor Pfactor
0237 0238 Float Cal.Factor PCalF
0239 0240 Float Cal.Factor internal Standard PCalFi
0241 0242 Float Cal.Value internal Standard PCalVi
0243 0243 U16 Gain Level Reference Signal GiRef
0244 0244 U16 Gain Level Measure Signal GiMes
0245 0246 Float Measure Range 1 RngUp[1]
0247 0248 Float Measure Range 2 RngUp[2]
0249 0250 U16 Reserved
:
:
Start End Data Type Description Remarks
----------------------------------------------------------------------------
Component 15 (=FLOW) Values
0901 0902 U32 Date Stamp last Calibration
0903 0904 U32 Time Stamp last Calibration
0905 0906 Float Actual Concentration PKnz
0907 0908 Float mExt add. and mult. correction PExtCor
0909 0910 Float mExt additive correction PExtAdd
0911 0912 Float mExt with ZERO-correction PExtRawN
0913 0914 Float mExt without ZERO-correction PExtRaw
0915 0916 Float Analog Input Signal [0..100%] PRef [0..4095digit]
0917 0918 Float Measure Signal [0..100%] PMes
0919 0920 Float Calibration Value PCalV
0921 0922 Float First Calibration Value PCal1
0923 0924 Float Last Calibration Value PCalLast
0925 0926 Float Actual Calibration Value PCalAct
0927 0928 Float First Zero Value PNul1
0929 0930 Float Last Zero Value PNulLast
0931 0932 Float Actual Zero Value PNulAct
0933 0934 Float Extra Offset [Absorb] Poffset
0935 0936 Float Extra Factor Pfactor
0937 0938 Float Cal.Factor PCalF
0939 0940 Float Cal.Factor internal Standard PCalFc
0941 0942 Float Cal.Value internal Standard PCalVc
0943 0943 U16 Gain Level Reference Signal GiRef
0944 0944 U16 Gain Level Measure Signal GiMes
0945 0946 Float Measure Range 1 RngUp[1]
0947 0948 Float Measure Range 2 RngUp[2]
0949 0950 U16 Reserved
