Note: Sample point index “0” means: Active sample points
TPAi, TPNi: Actual/Nominal temperature/pressure (i = 1..33)
Default settings are (x = A,N):
TPx01: O
2
sensor
TPx02: Detector
TPx03: Cell
TPx04: Filter wheels
TPx05: Heating controller 1 channel 1
TPx06: Heating controller 1 channel 2
TPx07: Heating controller 2 channel 1
TPx08: Heating controller 2 channel 2
etc.
P At the end of a secondary variable R, K, A, AI means: Previous value
S1i ith value from serial MCS protocol (i = 1..16)
Ti Timer (i = 1..116)
Fi Flag (i = 1..99)
Arithmetic functions:
SIN Sine
COS Cosine
ARCTAN Arcus Tangens
SQR Square
SQRT Square Root
EXP Exponential function
LN Natural logarithm
LG Decadic logarithm
INT Integer
SGN Sign change
ABSVAL Amount
PI Constant
Special functions
KONZ, CONC: Concentration, e.g. CONC [1,2]
(Concentration of sample point 1, component 2 )
EXT, ABS: Absorbance, e.g. ABS [1,2]
(Absorbance of sample point 1, component 2 )
MES: Measuring signal of a component, e.g. MES [1,2] measured value of sample point 1,
component 2
REF: Reference signal of a component, e.g. REF [1,2] reference value of sample point 1,
component 2
TPF1, LPF1: Low pass of 1
st
order, e.g. TPF1 (EXT [2.3],20), (filtering of absorption from sample point
2, component 3 with low pass of 1
st
order of 20 s.)
TPF2, LPF2: Low pass of second order
CAL: Mean square fit data, e.g. CAL (R3,1)
Calculation with result 3 as input signal for table 1.
1
R25..R32 are equivalent to TPA1..TPA8 (see secondary variable TPAi)
