Addr. Parameter C Setting Options Default Setting Comments
1808 50c-3 PICKUP 1A 1.00 .. 30.00 A; ∞ ∞ A 50c-3 Pickup
5A 5.00 .. 150.00 A; ∞ ∞ A
1809 50c-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 50c-3 Time Delay
1810 51c Drop-out Disk Emulation
Instantaneous
Disk Emulation Drop-out Characteristic
1811 51c IEC Curve Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1812 51c ANSI Curve Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1813 51c Recloser Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
Curve A (101) Recloser Curve
1814 51c-1 PICKUP 1A 0.10 .. 4.00 A; ∞ 1.00 A 51c-1 Pickup
5A 0.50 .. 20.00 A; ∞ 5.00 A
1815 51c-1 TIME DIAL 0.01 .. 20.00 sec; ∞ 0.50 sec 51c-1 Time dial
1816 51c-1 Drop-out Instantaneous
Disk Emulation
Disk Emulation Drop-out Characteristic
1817 51c-1 IEC Cur. NO
Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse 51c-1 IEC Curve
1818 51c-1 T adder 0.00 .. 30.00 sec 0.00 sec Constant time adder 51c-1
Functions
2.4 Dynamic Cold Load Pickup
