Subsection 3.1 Mounting and Connections of this manual tells you how to change between several setting
groups externally via binary inputs.
Settings
Addr. Parameter Setting Options Default Setting Comments
302 CHANGE Group A
Group B
Group C
Group D
Group E
Group F
Group G
Group H
Group I
Group J
Group K
Group L
Group M
Group N
Group O
Group P
Binary Input
Protocol
Group A Change to Another Setting Group
Information List
No.
Information Type of
Informa-
tion
Comments
- P-GrpA act IntSP Setting Group A is active
- P-GrpB act IntSP Setting Group B is active
- P-GrpC act IntSP Setting Group C is active
- P-GrpD act IntSP Setting Group D is active
- P-GrpE act IntSP Setting Group E is active
- P-GrpF act IntSP Setting Group F is active
- P-GrpG act IntSP Setting Group G is active
- P-GrpH act IntSP Setting Group H is active
- P-GrpI act IntSP Setting Group I is active
- P-GrpJ act IntSP Setting Group J is active
- P-GrpK act IntSP Setting Group K is active
- P-GrpL act IntSP Setting Group L is active
- P-GrpM act IntSP Setting Group M is active
- P-GrpN act IntSP Setting Group N is active
- P-GrpO act IntSP Setting Group O is active
- P-GrpP act IntSP Setting Group P is active
7 >Set Group Bit0 SP >Setting Group Select Bit 0
8 >Set Group Bit1 SP >Setting Group Select Bit 1
9 >Set Group Bit2 SP >Setting Group Select Bit 2
10 >Set Group Bit3 SP >Setting Group Select Bit 3
2.1.5.3
2.1.5.4
