Protocol-dependent Functions
Protocol → IEC 61850
Ethernet
DNP3 TCP Profinet
Ethernet
(EN100)
IEC 61850–5–
104
DNP3.0
Function ↓
Operational measured
values
yes yes yes yes yes
Count values yes yes yes yes yes
Fault recording yes yes no yes no
Remote protection
setting
no no no no no
User-defined indica-
tions and switching
objects
yes yes yes yes yes
Time synchronization yes yes yes yes yes
Indications with time
stamp
yes yes yes yes yes
Commissioning aids
Data transmission stop yes no no yes no
Creation of test
messages
yes no no yes no
Transmission mode cyclic/event cyclic/event cyclic/event
(DNP)
cyclic/event cyclic/event (DNP)
Baud rate up to 100
MBaud
up to 100
MBaud
up to 100
MBaud
up to 100
MBaud
9600 Bd to 57600
Bd
Typ Ethernet Ethernet Ethernet Ethernet RS485
