Siemens 7SC80 - Information List

Addr. Parameter Setting Options Default Setting Comments
5714 27-1Ph2B Pickup 10 .. 210 V 75 V 27-1 Phase 2B Pickup
5715 27-1Ph2B Pickup 10 .. 120 V 45 V 27-1 Phase 2B Pickup
5716 27-1Ph2C Pickup 10 .. 210 V 75 V 27-1 Phase 2C Pickup
5717 27-1Ph2C Pickup 10 .. 120 V 45 V 27-1 Phase 2C Pickup
5718 27-2Ph2A Pickup 10 .. 210 V 70 V 27-2 Phase 2A Pickup
5719 27-2Ph2A Pickup 10 .. 120 V 40 V 27-2 Phase 2A Pickup
5720 27-2Ph2B Pickup 10 .. 210 V 70 V 27-2 Phase 2B Pickup
5721 27-2Ph2B Pickup 10 .. 120 V 40 V 27-2 Phase 2B Pickup
5722 27-2Ph2C Pickup 10 .. 210 V 70 V 27-2 Phase 2C Pickup
5723 27-2Ph2C Pickup 10 .. 120 V 40 V 27-2 Phase 2C Pickup
5724 27-1 Ph2A Delay 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Phase 2A Time Delay
5725 27-1 Ph2B Delay 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Phase 2B Time Delay
5726 27-1 Ph2C Delay 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Phase 2C Time Delay
5727 27-2 Ph2A Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Phase 2A Time Delay
5728 27-2 Ph2B Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Phase 2B Time Delay
5729 27-2 Ph2C Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Phase 2C Time Delay
Information List
No. Information Type of
Informa-
tion
Comments
640.4101 27,59blkS2 IntSP 27, 59 blocked via operation Side2
31261 >BLOCK 27 S2 SP >BLOCK 27 undervolt. prot. Side2
31262 >27 I SUP. S2 SP >27-Switch current superv. ON Side2
31263 >BLOCK 27-1 S2 SP >BLOCK 27-1 Undervolt. prot. Side2
31264 >BLOCK 27-2 S2 SP >BLOCK 27-2 Undervolt. prot. Side2
31265 27 OFF S2 OUT 27 Undervolt.prot.switched OFF Side2
31266 27 BLOCKED S2 OUT 27 Undervolt. prot. is BLOCKED Side2
31267 27 ACTIVE S2 OUT 27 Undervolt. prot. is ACTIVE Side2
31268 27-1 PU S2 OUT 27-1 Undervolt. picked up Side2
31269 27-1 PU CS S2 OUT 27-1 PICKUP w/curr. superv Side2
31270 27-2 PU S2 OUT 27-2 Undervolt. picked up Side2
31271 27-2 PU CS S2 OUT 27-2 PICKUP w/curr. superv Side2
31272 27-1 TRIP S2 OUT 27-1 Undervoltage TRIP Side2
31273 27-2 TRIP S2 OUT 27-2 Undervoltage TRIP Side2
31274 >BLOCK 59 S2 SP >BLOCK 59 overvolt. prot. Side2
31275 59 OFF S2 OUT 59 Overvolt.prot.switched OFF Side2
31276 59 BLOCKED S2 OUT 59 Overvolt.prot.is BLOCKED Side2
31277 59 ACTIVE S2 OUT 59 Overvolt.prot.is ACTIVE Side2
31278 59-1 PU S2 OUT 59-1 Overvolt. picked up Side2
31279 59-1 TRIP S2 OUT 59-1 Overvolt. TRIP Side2
31280 59-2 PU S2 OUT 59-2 Overvolt. picked up Side2
31281 59-2 TRIP S2 OUT 59-2 Overvolt. TRIP Side2
31283 27-1 Ph2A PU OUT 27-1 Phase 2A Undervoltage pickup
31284 27-1 Ph2B PU OUT 27-1 Phase 2B Undervoltage pickup
31285 27-1 Ph2C PU OUT 27-1 Phase 2C Undervoltage pickup
2.30.2.7
Functions
2.30 Additional Applications with 6 Voltage Inputs
SIPROTEC Compact, 7SC80, Manual 437
E50417-G1140-C486-A8, Edition 07.2017
