Siemens 7SC80 - Settings; Information List; Malfunction Responses of the Monitoring Functions; Description

Information for dimensioning resistor R is given in the Chapter "Installation and Commissioning" under Config-
uration Notes in the Section "Trip Circuit Supervision".
Settings
Addr. Parameter Setting Options Default Setting Comments
8201 FCT 74TC ON
OFF
ON 74TC TRIP Circuit Supervision
8202 Alarm Delay 1 .. 30 sec 2 sec Delay Time for alarm
Information List
No. Information Type of
Informa-
tion
Comments
6851 >BLOCK 74TC SP >BLOCK 74TC
6852 >74TC trip rel. SP >74TC Trip circuit superv.: trip relay
6853 >74TC brk rel. SP >74TC Trip circuit superv.: bkr relay
6861 74TC OFF OUT 74TC Trip circuit supervision OFF
6862 74TC BLOCKED OUT 74TC Trip circuit supervision is BLOCKED
6863 74TC ACTIVE OUT 74TC Trip circuit supervision is ACTIVE
6864 74TC ProgFail OUT 74TC blocked. Bin. input is not set
6865 74TC Trip cir. OUT 74TC Failure Trip Circuit
Malfunction Responses of the Monitoring Functions
The malfunction responses of monitoring equipment are summarized in the following.
Description
Malfunction Responses
Depending on the type of malfunction discovered, an indication is sent, a restart of the processor system is
initiated, or the device is shut down. After three unsuccessful restart attempts, the device is also shut down.
The readiness relay opens and indicates with its NC contact that the device is malfunctioning. Moreover, the
red "ERROR" LED lights up and the green "RUN" LED goes out. If the internal auxiliary voltage also fails, all LEDs
are dark. Table 2-16 shows a summary of the monitoring functions and the malfunction responses of the
device.
Table 2-16
Summary of the Device's Malfunction Responses
Monitoring Possible causes Malfunction response Indication (No.) Output
Auxiliary voltage failure external
(auxiliary voltage)
internal
(converter)
Device shutdown all LEDs off
DOK
2)
drops
out
Buffer battery internal
(buffer battery)
Indication
Fail Battery (177)
Hardware Watchdog internal
(processor failure)
Restart attempt
1)
LED "ERROR"
DOK
2)
drops
out
Software Watchdog internal
(processor failure)
Restart attempt
1)
LED "ERROR"
DOK
2)
drops
out
2.12.2.3
2.12.2.4
2.12.3
2.12.3.1
Functions
2.12 Monitoring Functions
