Addr. Parameter Setting Options Default Setting Comments
5042 59-1 PhA Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Phase A Time Delay
5043 59-1 PhB Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Phase B Time Delay
5044 59-1 PhC Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Phase C Time Delay
5045 59-2 PhA Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Phase A Time Delay
5046 59-2 PhB Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Phase B Time Delay
5047 59-2 PhC Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Phase C Time Delay
5101 FCT 27 OFF
ON
Alarm Only
OFF 27 Undervoltage Protection
5102 27-1 PICKUP 10 .. 210 V 75 V 27-1 Pickup
5103 27-1 PICKUP 10 .. 120 V 45 V 27-1 Pickup
5106 27-1 DELAY 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Time Delay
5110 27-2 PICKUP 10 .. 210 V 70 V 27-2 Pickup
5111 27-2 PICKUP 10 .. 120 V 40 V 27-2 Pickup
5112 27-2 DELAY 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Time Delay
5113A 27-1 DOUT RATIO 1.01 .. 3.00 1.20 27-1 Dropout Ratio
5114A 27-2 DOUT RATIO 1.01 .. 3.00 1.20 27-2 Dropout Ratio
5120A CURRENT SUPERV. OFF
ON
ON Current Supervision
5130 27-1 PhA Pickup 10 .. 210 V 75 V 27-1 Phase A Pickup
5131 27-1 PhA Pickup 10 .. 120 V 45 V 27-1 Phase A Pickup
5132 27-1 PhB Pickup 10 .. 210 V 75 V 27-1 Phase B Pickup
5133 27-1 PhB Pickup 10 .. 120 V 45 V 27-1 Phase B Pickup
5134 27-1 PhC Pickup 10 .. 210 V 75 V 27-1 Phase C Pickup
5135 27-1 PhC Pickup 10 .. 120 V 45 V 27-1 Phase C Pickup
5136 27-2 PhA Pickup 10 .. 210 V 70 V 27-2 Phase A Pickup
5137 27-2 PhA Pickup 10 .. 120 V 40 V 27-2 Phase A Pickup
5138 27-2 PhB Pickup 10 .. 210 V 70 V 27-2 Phase B Pickup
5139 27-2 PhB Pickup 10 .. 120 V 40 V 27-2 Phase B Pickup
5140 27-2 PhC Pickup 10 .. 210 V 70 V 27-2 Phase C Pickup
5141 27-2 PhC Pickup 10 .. 120 V 40 V 27-2 Phase C Pickup
5142 27-1 PhA Delay 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Phase A Time Delay
5143 27-1 PhB Delay 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Phase B Time Delay
5144 27-1 PhC Delay 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Phase C Time Delay
5145 27-2 PhA Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Phase A Time Delay
5146 27-2 PhB Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Phase B Time Delay
5147 27-2 PhC Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Phase C Time Delay
Information List
No.
Information Type of
Informa-
tion
Comments
234.2100 27, 59 blk IntSP 27, 59 blocked via operation
2203 27-1 PhA pickup OUT 27-1 Phase A Undervoltage pickup
2204 27-1 PhB pickup OUT 27-1 Phase B Undervoltage pickup
2205 27-1 PhC pickup OUT 27-1 Phase C Undervoltage pickup
2.6.7
Functions
2.6 Voltage Protection 27, 59
SIPROTEC Compact, 7SC80, Manual 199
E50417-G1140-C486-A8, Edition 07.2017
