No. Information Type of
Informa-
tion
Comments
2206 27-1 PhA PU CS OUT 27-1 Phase A PICKUP w/curr. Supervision
2207 27-1 PhB PU CS OUT 27-1 Phase B PICKUP w/curr. Supervision
2208 27-1 PhC PU CS OUT 27-1 Phase C PICKUP w/curr. Supervision
2209 27-2 PhA pickup OUT 27-2 Phase A Undervoltage pickup
2210 27-2 PhB pickup OUT 27-2 Phase B Undervoltage pickup
2211 27-2 PhC pickup OUT 27-2 Phase C Undervoltage pickup
2212 27-2 PhA PU CS OUT 27-2 Phase A PICKUP w/curr. Supervision
2213 27-2 PhB PU CS OUT 27-2 Phase B PICKUP w/curr. Supervision
2214 27-2 PhC PU CS OUT 27-2 Phase C PICKUP w/curr. Supervision
2215 27-1 PhA TRIP OUT 27-1 Phase A Undervoltage TRIP
2216 27-1 PhB TRIP OUT 27-1 Phase B Undervoltage TRIP
2217 27-1 PhC TRIP OUT 27-1 Phase C Undervoltage TRIP
2218 27-2 PhA TRIP OUT 27-2 Phase A Undervoltage TRIP
2219 27-2 PhB TRIP OUT 27-2 Phase B Undervoltage TRIP
2220 27-2 PhC TRIP OUT 27-2 Phase C Undervoltage TRIP
2221 59-1 PhA pickup OUT 59-1 Phase A picked up
2222 59-1 PhB pickup OUT 59-1 Phase B picked up
2223 59-1 PhC pickup OUT 59-1 Phase C picked up
2224 59-1 Ph A TRIP OUT 59-1 Phase A TRIP
2225 59-1 Ph B TRIP OUT 59-1 Phase B TRIP
2226 59-1 Ph C TRIP OUT 59-1 Phase C TRIP
2227 59-2 PhA pickup OUT 59-2 Phase A picked up
2228 59-2 PhB pickup OUT 59-2 Phase B picked up
2229 59-2 PhC pickup OUT 59-2 Phase C picked up
2230 59-2 Ph A TRIP OUT 59-2 Phase A TRIP
2231 59-2 Ph B TRIP OUT 59-2 Phase B TRIP
2232 59-2 Ph C TRIP OUT 59-2 Phase C TRIP
2500 >BLOCK 59N DT SP >Block 59N Definite time Delay
2501 >BLOCK 59N IT SP >Block 59N Inverse time Delay
2502 59N DT BLOCKED OUT 59N Definite time delay is BLOCKED
2503 59N DT OFF OUT 59N DT is switched OFF
2504 59N DT ACTIVE OUT 59N DT is ACTIVE
2505 59N DT-1 PICKUP OUT 59N DT-1 PICKUP
2506 59N DT-1 TRIP OUT 59N DT-1 TRIP
2507 59N DT-2 PICKUP OUT 59N DT-2 PICKUP
2508 59N DT-2 TRIP OUT 59N DT-2 TRIP
2509 59N IT BLOCKED OUT 59N Inverse time delay is BLOCKED
2510 59N IT OFF OUT 59N IT is switched OFF
2511 59N IT ACTIVE OUT 59N IT is ACTIVE
2512 59N IT PICKUP OUT 59N IT PICKUP
2513 59N IT TRIP OUT 59N IT TRIP
6503 >BLOCK 27 SP >BLOCK 27 undervoltage protection
6505 >27 I SUPRVSN SP >27-Switch current supervision ON
6506 >BLOCK 27-1 SP >BLOCK 27-1 Undervoltage protection
6508 >BLOCK 27-2 SP >BLOCK 27-2 Undervoltage protection
Functions
2.6 Voltage Protection 27, 59
200 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
