Siemens 7SC80 - Information List

Addr. Parameter C Setting Options Default Setting Comments
3126 RESET DELAY 0 .. 60 sec 1 sec Reset Delay
3130 PU CRITERIA Vgnd OR INs
Vgnd AND INs
Vgnd OR INs Sensitive Ground Fault
PICKUP criteria
3131 M.of PU TD 1.00 .. 20.00 MofPU; ∞
0.01 .. 999.00 TD
Multiples of PU Time-Dial
3144 51Ns IEC CURVE Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
3145 51Ns ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
3146 51Ns Drop-out Disk Emulation
Instantaneous
Disk Emulation Drop-out characteristic
3150 50Ns-2 Vmin 10.0 .. 90.0 V 10.0 V 50Ns-2 minimum voltage
3150 50Ns-2 Vmin 0.4 .. 50.0 V 2.0 V 50Ns-2 minimum voltage
3151 50Ns-2 Phi -180.0 .. 180.0 ° -90.0 ° 50Ns-2 angle phi
3152 50Ns-2 DeltaPhi 0.0 .. 180.0 ° 30.0 ° 50Ns-2 angle delta phi
3153 50Ns-1 Vmin 10.0 .. 90.0 V 15.0 V 50Ns-1 minimum voltage
3153 50Ns-1 Vmin 0.4 .. 50.0 V 6.0 V 50Ns-1 minimum voltage
3154 50Ns-1 Phi -180.0 .. 180.0 ° -160.0 ° 50Ns-1 angle phi
3155 50Ns-1 DeltaPhi 0.0 .. 180.0 ° 100.0 ° 50Ns-1 angle delta phi
Information List
No.
Information Type of
Informa-
tion
Comments
1201 >BLOCK 64 SP >BLOCK 64
1202 >BLOCK 50Ns-2 SP >BLOCK 50Ns-2
1203 >BLOCK 50Ns-1 SP >BLOCK 50Ns-1
1204 >BLOCK 51Ns SP >BLOCK 51Ns
1207 >BLK 50Ns/67Ns SP >BLOCK 50Ns/67Ns
1211 50Ns/67Ns OFF OUT 50Ns/67Ns is OFF
1212 50Ns/67Ns ACT OUT 50Ns/67Ns is ACTIVE
1215 64 Pickup OUT 64 displacement voltage pick up
1217 64 TRIP OUT 64 displacement voltage element TRIP
1219 INs-a = VI Active comp. of sens Gnd Flt current
1220 INs-r = VI Reactive comp. of sens Gnd Flt current
1221 50Ns-2 Pickup OUT 50Ns-2 Pickup
1223 50Ns-2 TRIP OUT 50Ns-2 TRIP
1224 50Ns-1 Pickup OUT 50Ns-1 Pickup
1226 50Ns-1 TRIP OUT 50Ns-1 TRIP
2.13.6
Functions
2.13 Ground Fault Protection 64, 67N(s), 50N(s), 51N(s)
