Addr. Parameter Setting Options Default Setting Comments
5907A DO differential 0.04 .. 1.00 Hz 0.04 Hz Dropout differential
5908 81-1 PICKUP S2 40.00 .. 60.00 Hz 49.50 Hz 81-1 Pickup Side2
5909 81-1 PICKUP S2 50.00 .. 70.00 Hz 59.50 Hz 81-1 Pickup Side2
5910 81-1 DELAY S2 0.00 .. 100.00 sec; ∞ 60.00 sec 81-1 Time Delay Side2
5911 81-2 PICKUP S2 40.00 .. 60.00 Hz 49.00 Hz 81-2 Pickup Side2
5912 81-2 PICKUP S2 50.00 .. 70.00 Hz 59.00 Hz 81-2 Pickup Side2
5913 81-2 DELAY S2 0.00 .. 100.00 sec; ∞ 30.00 sec 81-2 Time Delay Side2
5914 81-3 PICKUP S2 40.00 .. 60.00 Hz 47.50 Hz 81-3 Pickup Side2
5915 81-3 PICKUP S2 50.00 .. 70.00 Hz 57.50 Hz 81-3 Pickup Side2
5916 81-3 DELAY S2 0.00 .. 100.00 sec; ∞ 3.00 sec 81-3 Time delay Side2
5917 81-4 PICKUP S2 40.00 .. 60.00 Hz 51.00 Hz 81-4 Pickup Side2
5918 81-4 PICKUP S2 50.00 .. 70.00 Hz 61.00 Hz 81-4 Pickup Side2
5919 81-4 DELAY S2 0.00 .. 100.00 sec; ∞ 30.00 sec 81-4 Time delay Side2
Information List
No. Information Type of
Informa-
tion
Comments
31316 >BLK 81 O/U S2 SP >BLOCK 81O/U Side2
31317 >BLK 81-1 S2 SP >BLOCK 81-1 Side2
31318 >BLK 81-2 S2 SP >BLOCK 81-2 Side2
31319 >BLK 81-3 S2 SP >BLOCK 81-3 Side2
31320 >BLK 81-4 S2 SP >BLOCK 81-4 Side2
31321 81 OFF S2 OUT 81 OFF Side2
31322 81 BLOCKED S2 OUT 81 BLOCKED Side2
31323 81 ACTIVE S2 OUT 81 ACTIVE Side2
31324 81 UV Blk S2 OUT 81 Under Voltage Block Side2
31325 81-1 PU S2 OUT 81-1 picked up Side2
31326 81-2 PU S2 OUT 81-2 picked up Side2
31327 81-3 PU S2 OUT 81-3 picked up Side2
31328 81-4 PU S2 OUT 81-4 picked up Side2
31329 81-1 TRIP S2 OUT 81-1 TRIP Side2
31330 81-2 TRIP S2 OUT 81-2 TRIP Side2
31331 81-3 TRIP S2 OUT 81-3 TRIP Side2
31332 81-4 TRIP S2 OUT 81-4 TRIP Side2
Voltage-Transformer Supervision of Side 2
Description
General
In practice, voltage-transformer faults occur rather rarely. More frequently, it is the fuses connected in series
to the voltage transformers which fail. Such a failure is detected by the voltage transformer supervision func-
tion and signaled with a warning indication. 1-, 2-, and 3-phase faults are detected.
The limit values and delay times for the function can be parameterized.
2.30.3.4
2.30.4
2.30.4.1
Functions
2.30 Additional Applications with 6 Voltage Inputs
