Addr. Parameter C Setting Options Default Setting Comments
2219 67N-2 w. Inrush NO
YES
NO 67N-2 with Inrush Restraint
2220 67N-TOC w. Inr. NO
YES
NO 67N-TOC with Inrush
Restraint
2225A 67-TOC T adder 0.00 .. 30.00 sec 0.00 sec Constant time adder 67-
TOC
2230 67-TOC-1 w. In. NO
YES
NO 67-TOC-1 with Inrush
Restraint
2231 67-TOC-2 w. In. NO
YES
NO 67-TOC-2 with Inrush
Restraint
2232 67-TOC-3 w. In. NO
YES
NO 67-TOC-3 with Inrush
Restraint
2233 67-TOC-4 w. In. NO
YES
NO 67-TOC-4 with Inrush
Restraint
2234 67N-TOC-1 w. I. NO
YES
NO 67N-TOC-1 with Inrush
Restraint
2235 67N-TOC-2 w. I. NO
YES
NO 67N-TOC-2 with Inrush
Restraint
2236 67N-TOC-3 w. I. NO
YES
NO 67N-TOC-3 with Inrush
Restraint
2237 67N-TOC-4 w. I. NO
YES
NO 67N-TOC-4 with Inrush
Restraint
2325A 67N-TOC T adder 0.00 .. 30.00 sec 0.00 sec Constant time adder 67N-
TOC
Information List
No.
Information Type of
Informa-
tion
Comments
5951 >BLK 50 1Ph SP >BLOCK 50 1Ph
5952 >BLK 50 1Ph-1 SP >BLOCK 50 1Ph-1
5953 >BLK 50 1Ph-2 SP >BLOCK 50 1Ph-2
5961 50 1Ph OFF OUT 50 1Ph is OFF
5962 50 1Ph BLOCKED OUT 50 1Ph is BLOCKED
5963 50 1Ph ACTIVE OUT 50 1Ph is ACTIVE
5966 50 1Ph-1 BLK OUT 50 1Ph-1 is BLOCKED
5967 50 1Ph-2 BLK OUT 50 1Ph-2 is BLOCKED
5971 50 1Ph Pickup OUT 50 1Ph picked up
5972 50 1Ph TRIP OUT 50 1Ph TRIP
5974 50 1Ph-1 PU OUT 50 1Ph-1 picked up
5975 50 1Ph-1 TRIP OUT 50 1Ph-1 TRIP
5977 50 1Ph-2 PU OUT 50 1Ph-2 picked up
5979 50 1Ph-2 TRIP OUT 50 1Ph-2 TRIP
5980 50 1Ph I: VI 50 1Ph: I at pick up
