Siemens 7SC80 - UL Certification Conditions

UL certification conditions
Output relays DC 24 V
5 A
1)
General Purpose
1 A
2)
General Purpose
DC 48 V 0.8 A General Purpose
DC 240 V 0.1 A General Purpose
AC 240 V
5 A
1)
General Purpose
1 A
2)
General Purpose
AC 120 V
1/6 hp
1)
AC 250 V
1/2 hp
1)
B300, R300
Voltage inputs Input voltage range
DC 300 V
1)
DC 150 V
2)
Battery Servicing of the circuitry involving the batteries and replacement of the lithium
batteries shall be done by a trained technician.
Replace Battery with Typ CR2032 Lithium-Battery; 3 V, 230 mAh only. Use of
another Battery may present a risk of fire or explosion. See manual for safety
instructions.
Caution: The battery used in this device may present a fire or chemical burn hazard
if mistreated. Do not recharge, disassemble, heat above 100 °C (212 °F) or incin-
erate.
Dispose of used battery promptly. Keep away from children.
Climatic Stress Tests Surrounding air temperature tsurr: max. 50 °C (122 °F), normal opera-
tion
tsurr: max. 70 °C (158 °F), normal opera-
tion
Constructive designs Field Wires of Control Circuits shall be separated from other circuits with respect to
the end use requirements!
Type 1 if mounted into a door or front cover of an enclosure.
1)
In this case the max. surrounding air temperature is 50 °C (122 °F).
2)
In this case the max. surrounding air temperature is 70 °C (158 °F).
