Function Name Enabled with Protection
Function
Enabled without Protection
Function
Recloser capacitor Test Yes Yes
Triple Single Mode Yes No
Flexible Functions 1...20 Yes No
Yes: Function available
No: Function not available
Sectionalizer Cold-Load-Pickup Detection
The sectionalizer Cold-Load-Pickup function can be turned ON or OFF in address 9502 Sec. CLP Det..
The sectionalizer cold load pickup threshold is set at address 9511 Sec. CLP PU. The sectionalizer cold load
drop-out threshold is set at address 9513 Sec. CLP DO. The parameter 9513 Sec. CLP DO must be set
greater than the parameter 9511 Sec. CLP PU, otherwise the sectionalizer CLP will be blocked.
The sectionalizer cold load pickup time delay is set at address 9512 Sec. CLP PU T. The sectionalizer cold
load drop-out time delay is set at address 9514 Sec. CLP DO T.
Sectionalizer Protection
The sectionalizer function can be turned ON or OFF in address 9501 FCT Sec..
The open sectionalizer counter is set at address 9521 Open Sec. Cnt. .
The minimum phase detection during normal condition threshold is set at address 9522 Min. Iph.
The minimum neutral detection during normal condition threshold is set at address 9523 Min. Ignd.
The minimum phase detection during cold load condition threshold is set at address 9524 Min. Iph CLP.
The minimum neutral detection during cold load condition threshold is set at address 9525 Min. Ignd CLP.
The time to confirm trip is set at address 9526 T. to con. Trip.
The time to open command is set at address 9527 Time to open.
The time to reset after last increase is set at address 9528 Time to reset.
Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
Addr.
Parameter C Setting Options Default Setting Comments
9501 FCT Sec. OFF
ON
OFF Sectionalizer Function
9502 Sec. CLP Det. OFF
ON
OFF Sec. Cold Load Pickup
Detection
9511 Sec. CLP PU 1A 0.04 .. 5.00 A 0.10 A Sec. Cold Load Pickup
5A 0.20 .. 25.00 A 0.50 A
9512 Sec. CLP PU T 0.00 .. 360.00 sec 0.10 sec Sec. Cold Load Pickup Time
Delay
9513 Sec. CLP DO 1A 0.04 .. 5.00 A 0.20 A Sec. Cold Load Drop-out
5A 0.20 .. 25.00 A 1.00 A
9514 Sec. CLP DO T 0.00 .. 360.00 sec 10.00 sec Sec. Cold Load Drop-out
Time Delay
9521 Open Sec. Cnt. 1 .. 20 2 Open Sec. Counter
9522 Min. Iph 1A 0.04 .. 30.00 A; ∞ 2.00 A Minimum Phase Current
5A 0.20 .. 150.00 A; ∞ 10.00 A
9523 Min. Ignd 1A 0.04 .. 30.00 A; ∞ 0.50 A Minimum Neutral Current
5A 0.20 .. 150.00 A; ∞ 2.50 A
2.15.3
Functions
2.15 Sectionalizer Function
SIPROTEC Compact, 7SC80, Manual 307
E50417-G1140-C486-A8, Edition 07.2017
