Addr. Parameter C Setting Options Default Setting Comments
9524 Min. Iph CLP 1A 0.04 .. 30.00 A; ∞ 4.00 A Minimum Phase During
Cold Load
5A 0.20 .. 150.00 A; ∞ 20.00 A
9525 Min. Ignd CLP 1A 0.04 .. 30.00 A; ∞ 1.00 A Minimum Neutral During
Cold Load
5A 0.20 .. 150.00 A; ∞ 5.00 A
9526 T. to con. Trip 0.01 .. 30.00 sec 0.15 sec Time to confirm trip
9527 Time to open 0.00 .. 360.00 sec 5.00 sec Time to open command
9528 Time to reset 0.00 .. 360.00 sec 10.00 sec Time to reset after last
increase
Information List
No. Information Type of
Informa-
tion
Comments
31175 >BLK. Sec. CLP SP >BLOCK Sec. Cold Load Pickup
31176 Sec. CLP OFF OUT Sec. Cold-Load-Pickup switched OFF
31177 Sec. CLP BLK. OUT Sec. Cold-Load-Pickup is BLOCKED
31178 Sec. CLP run. OUT Sec. Cold-Load-Pickup is RUNNING
31179 Sec. Dyn set. OUT Sec. Dynamic Settings are ACTIVE
31180 >BLOCK Sec. SP >BLOCK Sectionalizer
31181 Sec. OFF OUT Sectionalizer switched OFF
31182 Sec. BLOCKED OUT Sectionalizer is BLOCKED
31183 Sec. picked up OUT Sectionalizer picked up
31184 Sec. counter VI Sectionalizer counter
31185 Sec. open OUT Sectionalizer open command
31186 Sec. ACTIVE OUT Sectionalizer is ACTIVE
31188 Sec. Ia = VI Primary Sectionalizer fault current Ia
31189 Sec. Ib = VI Primary Sectionalizer fault current Ib
31190 Sec. Ic = VI Primary Sectionalizer fault current Ic
31191 Sec. In = VI Primary Sectionalizer fault current In
2.15.4
Functions
2.15 Sectionalizer Function
308 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
