NOTE
With the parameter 613 Gnd O/Cprot. w. in the Power System Data 1 (see 2.1.3.2 Setting Notes), you
can identify whether the neutral currents IN in sectionalizer use the measured values Ignd (measured)
or the values 3I0 (calcul.) calculated from the 3-phase currents.
The timer symbol of parameter 9528 means: when the rising edge comes, timer starts. The timer restarts
when the next rising edge comes.
Setting Notes
General
The sectionalizer protection is only in effect and accessible if address 376 Sectionalizer is set to With
prot. or Without prot..
If you select the option Without prot., the functions marked with No in the following table, are switched
off completely and these protections in all setting groups are hidden, although these protections are set to be
enabled in device configuration.
If you select the option With prot., the protections in all setting groups work normally.
If the sectionalizer function is not required, then Disabled is set.
The following table shows the functions influenced by the sectionalizer. The functions marked with No are
protection- related functions, which are switched off completely when Without prot. is chosen.
Table 2-19 The Functions Influenced by the Sectionalizer
Function Name Enabled with Protection
Function
Enabled without Protection
Function
Setting Group Change Option Yes Yes
Oscillographic Fault Records Yes Yes
50/51 Phase/Ground Overcurrent Yes No
67 Directional Phase/Ground Overcurrent Yes No
Cold Load Pickup Yes No
27, 59 Under/Overvoltage Protection Yes No
27, 59 Under/Overvolt. Prot. Side2 Yes No
46 Negative Sequence Protection Yes No
81 Over/Underfrequency Protection Yes No
81 Over/Underfrequency Prot. Side2 Yes No
49 Thermal Overload Protection Yes No
Measurement Supervision Yes Yes
74TC Trip Circuit Supervision Yes Yes
64, 50Ns, 67Ns (sensitive) Ground fault Yes No
79 Auto-Reclose Function Yes No
Fault Locator Yes No
50BF Breaker Failure Protection Yes No
Demand Measurement Setup Yes Yes
Min/Max Measurement Setup Yes Yes
Energy Yes Yes
50 1Ph Yes No
47 Negative Phase Sequence Overvoltage Yes No
27/59 Over/under volt. Prot. for Vx Yes No
Capacitor Control Yes No
Tap Changer Yes No
2.15.2
Functions
2.15 Sectionalizer Function
