Addr. Parameter C Setting Options Default Setting Comments
5511 60VTS V2 7 .. 110 V 7 V 60VTS Threshold V2
5512 60VTS V0 7 .. 110 V 7 V 60VTS Threshold V0
5513 60VTS I2 1A 0.10 .. 1.00 A 0.10 A 60VTS Threshold I2
5A 0.50 .. 5.00 A 0.50 A
5514 60VTS I0 1A 0.10 .. 1.00 A 0.10 A 60VTS Threshold I0
5A 0.50 .. 5.00 A 0.50 A
5515 60VTS I1 load 1A 0.10 .. 1.00 A 0.10 A 60VTS Threshold I1 load
5A 0.50 .. 5.00 A 0.50 A
5516 60VTS I1 fault 1A 0.10 .. 10.00 A 10.00 A 60VTS Threshold I1 fault
5A 0.50 .. 50.00 A 50.00 A
5517 60VTS V1 1 .. 110 V 15 V 60VTS Threshold V1
5518 60VTS T-Delay 0.03 .. 320.00 sec 10.00 sec 60VTS Time Delay
5520 60CTS OFF
ON
OFF 60CTS Current Transformer
Supervision
5521 60CTS V2 7 .. 110 V 7 V 60CTS Threshold V2
5522 60CTS I2 1A 0.04 .. 1.00 A 0.04 A 60CTS Threshold I2
5A 0.20 .. 5.00 A 0.20 A
5523 60CTS T-Delay 0.03 .. 320.00 sec 10.00 sec 60CTS Time Delay
8101 MEASURE. SUPERV OFF
ON
ON Measurement Supervision
8102 BALANCE V-LIMIT 10 .. 100 V 50 V Voltage Threshold for
Balance Monitoring
8103 BAL. FACTOR V 0.58 .. 0.90 0.75 Balance Factor for Voltage
Monitor
8104 BALANCE I LIMIT 1A 0.10 .. 1.00 A 0.50 A Current Threshold for
Balance Monitoring
5A 0.50 .. 5.00 A 2.50 A
8105 BAL. FACTOR I 0.10 .. 0.90 0.50 Balance Factor for Current
Monitor
8106 Σ I THRESHOLD 1A 0.05 .. 2.00 A; ∞ 0.10 A Summated Current Moni-
toring Threshold
5A 0.25 .. 10.00 A; ∞ 0.50 A
8107 Σ I FACTOR 0.00 .. 0.95 0.10 Summated Current Moni-
toring Factor
8109 FAST Σi MONIT OFF
ON
ON Fast Summated Current
Monitoring
Information List
No.
Information Type of
Informa-
tion
Comments
161 Fail I Superv. OUT Failure: General Current Supervision
162 Failure Σ I OUT Failure: Current Summation
163 Fail I balance OUT Failure: Current Balance
167 Fail V balance OUT Failure: Voltage Balance
170 Fail VT Superv. OUT Failure: VT Supervision (alarm instant.)
171 Fail Ph. Seq. OUT Failure: Phase Sequence
175 Fail Ph. Seq. I OUT Failure: Phase Sequence Current
176 Fail Ph. Seq. V OUT Failure: Phase Sequence Voltage
197 MeasSup OFF OUT Measurement Supervision is switched OFF
2.12.1.10
Functions
2.12 Monitoring Functions
SIPROTEC Compact, 7SC80, Manual 241
E50417-G1140-C486-A8, Edition 07.2017
