Communication Interfaces
User Interface
Connection At the front, non-isolated, USB type B socket for connecting a
personal computer
Operation for DIGSI V4.85 and higher versions via USB 2.0 full
speed
Operation with DIGSI
Transmission speed up to 12 Mbit/s max.
Bridgeable distance 5 m
Port F
DNP3.0
Terminal Back case bottom, mounting location “B”, 9 pin DSUB socket
Test voltage 500 V; 50 Hz
Transmission speed Up to 57,600 Bd
Bridgeable distance max. 1 km
Ethernet electrical (EN 100) for IEC61850, DNP3 TCP, PROFINET, IEC60870-5-104 and DIGSI
Connection 2 x RJ45 socket
100 BaseT acc. to IEEE802.3
Line CAT 5 (twisted and screened in pairs)
Test voltage (for socket) 500 V; 50 Hz
Transmission speed 100 MBit/s
Maximum distance of transmission 20 m
Ethernet optical (EN 100 O SM or mulitmode) for IEC61850, DNP3 TCP, PROFINET, IEC60870-5-104 and
DIGSI
Connection Duplex-LC, 100BaseF in acc. with IEEE802.3
Transmission speed 100 MBit/s
Fiber types Singlemode optical fiber G9 μm/125 μm
Multimode optical fiber G50 μm/125 μm, G62,5μm/125 μm
Permissible bending radii for indoor cable r
min
= 5 cm
for outdoor cable r
min
= 20 cm
Maximum distance of transmission max. 24 km for singlemode
Transmitter
Optical wavelength λc 1270 nm to 1360 nm
Output power P
OUT
-15 dBm to -8 dBm
Receiver
Sensitivity P
IN
Min min. -31 dBm
Overload P
IN
Max max. -8 dBm
GPS Connection
Connection
SMB socket (subminiature B) at device
Active GPS antenna
5 V, max. 50 mA
4.1.4
Technical Data
4.1 General Device Data
