If the binary input time is set to ∞, the length of the record equals the time that the binary input is activated
(static), but not longer than the MAX. LENGTH (address 403).
Settings
Addr. Parameter Setting Options Default Setting Comments
401 WAVEFORMTRIGGER Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
402 WAVEFORM DATA Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
403 MAX. LENGTH 0.30 .. 6.00 sec 2.00 sec Max. length of a Waveform
Capture Record
404 PRE. TRIG. TIME 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
405 POST REC. TIME 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
406 BinIn CAPT.TIME 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
Information List
No. Information Type of
Informa-
tion
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
203 Wave. deleted OUT_Ev Waveform data deleted
30053 Fault rec. run. OUT Fault recording is running
Settings Groups
Up to 16 different setting groups can be created for establishing the device's function settings.
Description
Changing Setting Groups
The setting groups can be changed during operation locally via the Web Monitor, via binary inputs (if config-
ured correspondingly), or via the interfaces. For safety reasons, it is not possible to change between setting
groups during a power system fault.
A setting group includes the parameter values for all functions that have been selected as Enabled during
configuration (see Section 2.1.1.2 Setting Notes). In 7SC80 devices, 16 independent setting groups (A to P)
are supported. Whereas the setting values may vary, the selected functions of each setting group remain the
same.
Setting Notes
General
If the setting group change option is not required, Group A is the default selection. Then, the rest of this
section is not applicable.
If the changeover option is desired, group changeover must be set to Grp Chge OPTION = Enabled
(address 103) when the function extent is configured. For the setting of the function parameters, each of the
required setting groups A to P (a maximum of 16) must be configured in sequence. The SIPROTEC 4 System
Description gives further information on how to copy setting groups or reset them to their status at delivery
and also how to change from one setting group to another.
2.1.4.3
2.1.4.4
2.1.5
2.1.5.1
2.1.5.2
Functions
2.1 General
SIPROTEC Compact, 7SC80, Manual 63
E50417-G1140-C486-A8, Edition 07.2017
