Addr. Parameter Setting Options Default Setting Comments
6107 SYNC V1<V2> YES
NO
NO ON-Command at V1< and V2>
6108 SYNC V1>V2< YES
NO
NO ON-Command at V1> and V2<
6109 SYNC V1<V2< YES
NO
NO ON-Command at V1< and V2<
6110A Direct CO YES
NO
NO Direct ON-Command
6111A TSUP VOLTAGE 0.00 .. 60.00 sec 0.10 sec Supervision time of V1>;V2> or
V1<;V2<
6112 T-SYN. DURATION 0.01 .. 1200.00 sec; ∞ 30.00 sec Maximum duration of Synchroni-
zation
6113A 25 Synchron YES
NO
YES Switching at synchronous condi-
tion
6121 Balancing V1/V2 0.50 .. 2.00 1.00 Balancing factor V1/V2
6122A ANGLE ADJUSTM. 0 .. 360 ° 0 ° Angle adjustment (transformer)
6123 CONNECTIONof V2 A-G
B-G
C-G
A-B
B-C
C-A
A-B Connection of V2
6125 VT Vn2, primary 0.10 .. 800.00 kV 20.00 kV VT nominal voltage V2, primary
6150 dV SYNCHK V2>V1 0.5 .. 50.0 V 5.0 V Maximum voltage difference
V2>V1
6151 dV SYNCHK V2<V1 0.5 .. 50.0 V 5.0 V Maximum voltage difference
V2<V1
6152 df SYNCHK f2>f1 0.01 .. 2.00 Hz 0.10 Hz Maximum frequency difference
f2>f1
6153 df SYNCHK f2<f1 0.01 .. 2.00 Hz 0.10 Hz Maximum frequency difference
f2<f1
6154 dα SYNCHK α2>α1 2 .. 80 ° 10 ° Maximum angle difference
alpha2>alpha1
6155 dα SYNCHK α2<α1 2 .. 80 ° 10 ° Maximum angle difference
alpha2<alpha1
Information List
No.
Information Type of
Informa-
tion
Comments
170.0001 >25-1 act SP >25-group 1 activate
170.0043 >25 Sync requ. SP >25 Synchronization request
170.0049 25 CloseRelease OUT 25 Sync. Release of CLOSE Command
170.0050 25 Sync. Error OUT 25 Synchronization Error
170.0051 25-1 BLOCK OUT 25-group 1 is BLOCKED
170.2007 25 Measu. req. SP 25 Sync. Measuring request of Control
170.2008 >BLK 25-1 SP >BLOCK 25-group 1
170.2009 >25direct CO SP >25 Direct Command output
2.20.8
Functions
2.20 Synchrocheck
346 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
