Addr. Parameter C Setting Options Default Setting Comments
2235 67N-TOC-2 w. I. NO
YES
NO 67N-TOC-2 with Inrush
Restraint
2236 67N-TOC-3 w. I. NO
YES
NO 67N-TOC-3 with Inrush
Restraint
2237 67N-TOC-4 w. I. NO
YES
NO 67N-TOC-4 with Inrush
Restraint
2325A 67N-TOC T adder 0.00 .. 30.00 sec 0.00 sec Constant time adder 67N-
TOC
Information List
No. Information Type of
Informa-
tion
Comments
2518 67-2 InRushPU OUT 67-2 InRush picked up
2519 67N-2 InRushPU OUT 67N-2 InRush picked up
2603 67N-3 TRIP OUT 67N-3 TRIP
2604 >BLK 67/67-TOC SP >BLOCK 67/67-TOC
2605 67N-3 BLOCKED OUT 67N-3 is blocked
2606 67-3 BLOCKED OUT 67-3 is BLOCKED
2614 >BLK 67N/67NTOC SP >BLOCK 67N/67N-TOC
2615 >BLOCK 67-2 SP >BLOCK 67-2
2616 >BLOCK 67N-2 SP >BLOCK 67N-2
2617 >BLOCK 67-3 SP >BLOCK 67-3
2618 >BLOCK 67N-3 SP >BLOCK 67N-3
2621 >BLOCK 67-1 SP >BLOCK 67-1
2622 >BLOCK 67-TOC SP >BLOCK 67-TOC
2623 >BLOCK 67N-1 SP >BLOCK 67N-1
2624 >BLOCK 67N-TOC SP >BLOCK 67N-TOC
2628 Phase A forward OUT Phase A forward
2629 Phase B forward OUT Phase B forward
2630 Phase C forward OUT Phase C forward
2632 Phase A reverse OUT Phase A reverse
2633 Phase B reverse OUT Phase B reverse
2634 Phase C reverse OUT Phase C reverse
2635 Ground forward OUT Ground forward
2636 Ground reverse OUT Ground reverse
2637 67-1 BLOCKED OUT 67-1 is BLOCKED
2642 67-2 picked up OUT 67-2 picked up
2646 67N-2 picked up OUT 67N-2 picked up
2647 67-2 Time Out OUT 67-2 Time Out
2648 67N-2 Time Out OUT 67N-2 Time Out
2649 67-2 TRIP OUT 67-2 TRIP
2651 67/67-TOC OFF OUT 67/67-TOC switched OFF
2652 67 BLOCKED OUT 67/67-TOC is BLOCKED
2653 67 ACTIVE OUT 67/67-TOC is ACTIVE
2655 67-2 BLOCKED OUT 67-2 is BLOCKED
2.3.12
Functions
2.3 Directional Overcurrent Protection 67, 67N
SIPROTEC Compact, 7SC80, Manual 147
E50417-G1140-C486-A8, Edition 07.2017
