Siemens 7SC80 - Page 146

Addr. Parameter C Setting Options Default Setting Comments
1675 67N-TOC-4 Rec. NO
Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
NO 67N-TOC-4 Recloser Curve
1685 67N-TOC-1MinO.T 0.00 .. 30.00 sec 0.01 sec Min Operating Time 67N-
TOC-1
1686 67N-TOC-2MinO.T 0.00 .. 30.00 sec 0.01 sec Min Operating Time 67N-
TOC-2
1687 67N-TOC-3MinO.T 0.00 .. 30.00 sec 0.01 sec Min Operating Time 67N-
TOC-3
1688 67N-TOC-4MinO.T 0.00 .. 30.00 sec 0.01 sec Min Operating Time 67N-
TOC-4
2215 67-1 w. Inrush NO
YES
NO 67-1 with Inrush Restraint
2216 67-2 w. Inrush NO
YES
NO 67-2 with Inrush Restraint
2217 67-TOC w. Inru. NO
YES
NO 67-TOC with Inrush
Restraint
2218 67N-1 w. Inrush NO
YES
NO 67N-1 with Inrush Restraint
2219 67N-2 w. Inrush NO
YES
NO 67N-2 with Inrush Restraint
2220 67N-TOC w. Inr. NO
YES
NO 67N-TOC with Inrush
Restraint
2225A 67-TOC T adder 0.00 .. 30.00 sec 0.00 sec Constant time adder 67-
TOC
2230 67-TOC-1 w. In. NO
YES
NO 67-TOC-1 with Inrush
Restraint
2231 67-TOC-2 w. In. NO
YES
NO 67-TOC-2 with Inrush
Restraint
2232 67-TOC-3 w. In. NO
YES
NO 67-TOC-3 with Inrush
Restraint
2233 67-TOC-4 w. In. NO
YES
NO 67-TOC-4 with Inrush
Restraint
2234 67N-TOC-1 w. I. NO
YES
NO 67N-TOC-1 with Inrush
Restraint
Functions
2.3 Directional Overcurrent Protection 67, 67N
146 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
