Siemens 7SC80 - Information List

Information List
No. Information Type of
Informa-
tion
Comments
2187 >BLOCK 27 Vx SP >BLOCK 27 under voltage prot. Vx
2188 27 Vx OFF OUT 27 under volt. Vx switched OFF
2189 27 Vx BLOCKED OUT 27 under volt. Vx is BLOCKED
2190 27 Vx ACTIVE OUT 27 under volt. Vx is ACTIVE
2191 27-1 Vx PU OUT 27-1 under volt. Vx PICKUP
2192 27-1 Vx TRIP OUT 27-1 under volt. Vx TRIP
2193 27-2 Vx PU OUT 27-2 under volt. Vx PICKUP
2194 27-2 Vx TRIP OUT 27-2 under volt. Vx TRIP
2195 >BLOCK 59 Vx SP >BLOCK 59 over voltage prot. Vx
2196 59 Vx OFF OUT 59 over volt prot. Vx switched OFF
2197 59 Vx BLOCKED OUT 59 over voltage Vx is BLOCKED
2198 59 Vx ACTIVE OUT 59 over voltage Vx is ACTIVE
2199 59-1 Vx PU OUT 59-1 over voltage Vx PICKUP
2200 59-1 Vx TRIP OUT 59-1 over voltage Vx TRIP
2201 59-2 Vx PU OUT 59-2 over voltage Vx PICKUP
2202 59-2 Vx TRIP OUT 59-2 over voltage Vx TRIP
2.8.4
Functions
2.8 27/59 Under/Over Voltage for Vx
