If the protection function is switched ON, the limit values have been exceeded, and the delay time elapsed,
tripping, trip log, and fault recording are initiated.
When set to Alarm Only, no trip command is given, no trip log is started, and no spontaneous fault indica-
tion is issued.
You can set the pickup thresholds of the two voltage elements at address 2251 47NPS-1 Pickup and 2254
47NPS-2 Pickup. No generally binding specifications can be given for the pickup values, because they
depend on the actual system configuration.
The associated dropout ratios are set at address 2252 47NPS-1 D.Ratio and address 2255 47NPS-2
D.Ratio.
You can specify the trip delay time for each element at address 2253 47NPS-1 Delay and address 2256
47NPS-2 Delay. Select the time setting so that permitted short-term voltage peaks caused by switching
operations do not initiate tripping, but stationary overvoltages are cleared in time.
Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
Addr. Parameter Setting Options Default Setting Comments
2250 FCT 47NPS OFF
ON
Alarm Only
OFF 47 Negative Phase Sequence
Overvoltage
2251 47NPS-1 Pickup 2 .. 240 V 30 V 47NPS-1 Pickup
2252A 47NPS-1 D.Ratio 0.90 .. 0.99 0.95 47NPS-1 Drop out Ratio
2253 47NPS-1 Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 47NPS-1 Time Delay
2254 47NPS-2 Pickup 2 .. 240 V 50 V 47NPS-2 Pickup
2255A 47NPS-2 D.Ratio 0.90 .. 0.99 0.95 47NPS-2 Drop out Ratio
2256 47NPS-2 Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 47NPS-2 Time Delay
Information List
No.
Information Type of
Informa-
tion
Comments
2520 >BLOCK 47NPS SP >BLOCK 47NPS
2521 47NPS OFF OUT 47NPS is switched OFF
2522 47NPS BLOCKED OUT 47NPS is BLOCKED
2523 47NPS ACTIVE OUT 47NPS is ACTIVE
2524 47NPS-2 Pickup OUT 47NPS-2 picked up
2525 47NPS-1 Pickup OUT 47NPS-1 picked up
2526 47NPS TRIP OUT 47NPS TRIP
2527 47NPS-2 TRIP OUT 47NPS-2 TRIP
2528 47NPS-1 TRIP OUT 47NPS-1 TRIP
2.7.3
2.7.4
Functions
2.7 47 Negative Phase Sequence Overvoltage
SIPROTEC Compact, 7SC80, Manual 203
E50417-G1140-C486-A8, Edition 07.2017
