Settings
Addr. Parameter Setting Options Default Setting Comments
5601 FCT 59 S2 OFF
ON
Alarm Only
OFF 59 Overvoltage Protection Side2
5602 59-1 PICKUP S2 20 .. 260 V 110 V 59-1 Pickup Side2
5603 59-1 PICKUP S2 20 .. 150 V 110 V 59-1 Pickup Side2
5604 59-1 PU V1 S2 20 .. 240 V 110 V 59-1 Pickup V1 Side2
5605 59-1 DELAY S2 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Time Delay Side2
5606 59-2 PICKUP S2 20 .. 260 V 120 V 59-2 Pickup Side2
5607 59-2 PICKUP S2 20 .. 150 V 120 V 59-2 Pickup Side2
5608 59-2 PU V1 S2 20 .. 240 V 120 V 59-2 Pickup V1 Side2
5609 59-2 DELAY S2 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Time Delay Side2
5610A 59-1 DOUT S2 0.90 .. 0.99 0.95 59-1 Dropout Ratio Side2
5611A 59-2 DOUT S2 0.90 .. 0.99 0.95 59-2 Dropout Ratio Side2
5612 59-1Ph2A Pickup 20 .. 260 V 110 V 59-1 Phase 2A Pickup
5613 59-1Ph2A Pickup 20 .. 150 V 110 V 59-1 Phase 2A Pickup
5614 59-1Ph2B Pickup 20 .. 260 V 110 V 59-1 Phase 2B Pickup
5615 59-1Ph2B Pickup 20 .. 150 V 110 V 59-1 Phase 2B Pickup
5616 59-1Ph2C Pickup 20 .. 260 V 110 V 59-1 Phase 2C Pickup
5617 59-1Ph2C Pickup 20 .. 150 V 110 V 59-1 Phase 2C Pickup
5618 59-2Ph2A Pickup 20 .. 260 V 120 V 59-2 Phase 2A Pickup
5619 59-2Ph2A Pickup 20 .. 150 V 120 V 59-2 Phase 2A Pickup
5620 59-2Ph2B Pickup 20 .. 260 V 120 V 59-2 Phase 2B Pickup
5621 59-2Ph2B Pickup 20 .. 150 V 120 V 59-2 Phase 2B Pickup
5622 59-2Ph2C Pickup 20 .. 260 V 120 V 59-2 Phase 2C Pickup
5623 59-2Ph2C Pickup 20 .. 150 V 120 V 59-2 Phase 2C Pickup
5624 59-1 Ph2A Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Phase 2A Time Delay
5625 59-1 Ph2B Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Phase 2B Time Delay
5626 59-1 Ph2C Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Phase 2C Time Delay
5627 59-2 Ph2A Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Phase 2A Time Delay
5628 59-2 Ph2B Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Phase 2B Time Delay
5629 59-2 Ph2C Delay 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Phase 2C Time Delay
5701 FCT 27 S2 OFF
ON
Alarm Only
OFF 27 Undervoltage Protection Side2
5702 27-1 PICKUP S2 10 .. 210 V 75 V 27-1 Pickup Side2
5703 27-1 PICKUP S2 10 .. 120 V 45 V 27-1 Pickup Side2
5704 27-1 DELAY S2 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Time Delay Side2
5705 27-2 PICKUP S2 10 .. 210 V 70 V 27-2 Pickup Side2
5706 27-2 PICKUP S2 10 .. 120 V 40 V 27-2 Pickup Side2
5707 27-2 DELAY S2 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Time Delay Side2
5708A 27-1 DOUT S2 1.01 .. 3.00 1.20 27-1 Dropout Ratio Side2
5709A 27-2 DOUT S2 1.01 .. 3.00 1.20 27-2 Dropout Ratio Side2
5710A CURRENT SUPERV. OFF
ON
OFF Current Supervision
5712 27-1Ph2A Pickup 10 .. 210 V 75 V 27-1 Phase 2A Pickup
5713 27-1Ph2A Pickup 10 .. 120 V 45 V 27-1 Phase 2A Pickup
2.30.2.6
Functions
2.30 Additional Applications with 6 Voltage Inputs
