Siemens 7SC80 - Functional Scope

Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 OSC. FAULT REC. Disabled
Enabled
Enabled Oscillographic Fault Records
112 Charac. Phase Disabled
Definite Time
TOC IEC
TOC ANSI
Recloser Curves
User Defined PU
User def. Reset
All Curves
Definite Time 50/51
113 Charac. Ground Disabled
Definite Time
TOC IEC
TOC ANSI
Recloser Curves
User Defined PU
User def. Reset
All Curves
Definite Time 50N/51N
115 67/67-TOC Disabled
Definite Time
TOC IEC
TOC ANSI
Recloser Curves
User Defined PU
User def. Reset
All Curves
Definite Time 67, 67-TOC
116 67N/67N-TOC Disabled
Definite Time
TOC IEC
TOC ANSI
Recloser Curves
User Defined PU
User def. Reset
All Curves
Definite Time 67N, 67N-TOC
117 Coldload Pickup Disabled
Enabled
Disabled Cold Load Pickup
122 InrushRestraint Disabled
Enabled
Disabled 2nd Harmonic Inrush Restraint
127 50 1Ph Disabled
Enabled
Disabled 50 1Ph
130 S.Gnd.F.Dir.Ch cos φ / sin φ
V0/I0 φ mea.
cos φ / sin φ (sens.) Ground fault dir. character-
istic
F.1
Functions, Settings, Information
F.1 Functional Scope
618 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
