Ordering Information 7SC803
Recloser Controller 6 7 8 9 10 11 12 13 14 15 16 Suffix
7 S C 8 0 – – 3 F +
Basic functions, BO/BI Pos. 6
Housing 20 BI, 15 BO, 1 live contact 3
Current and voltage inputs, default settings Pos. 7
3 x Ι LoPo/LPS, 6 x V
3
4 x Ι
ph
= 1 A/5 A , Ι
e
= 1 A/5 A, 6 x V
4
3 x Ι
ph
= 1 A/5 A, 1 x Ι
Ns
(sensitive) = 0.001 A to 1.6 A/0.005 A to 8 A, 6 x V
6
Auxiliary voltage (power supply) Pos. 8
DC 60 V to 250 V, AC 115 V, AC 230 V 1
DC 24 V/48 V 2
DC 24 V/48 V with battery monitoring 3
Construction Pos. 9
Surface-mounted housing, screw-type terminals, without HMI A
Surface-mounting housing, flush-mounting housing with HMI B
Surface-mounting housing, screw terminals, with detached HMI C
Region-specific language default settings and function versions Pos. 10
Region DE, IEC, language German (language can be changed) A
Region world, IEC/ANSI, language English (language can be changed) B
Region US, ANSI, language English (US) (language can be changed) C
Region world, IEC/ANSI, language French (language can be changed) D
Region world, IEC/ANSI, language Spanish (language can be changed) E
Region world, IEC/ANSI, language Russian (language can be changed) G
System interfaces Pos. 11
No communication module 0
For further interface options, see Additional Information in the following 9
Additional information for additional interfaces Suffix
100 Mbit Ethernet, 2 x RJ45 connector + L x R
100 Mbit Ethernet, optical 2 x LC connector, multimode + L x S
100 Mbit Ethernet, optical 2 x LC connectors, singlemode 24 km + L x T
DNP3.0 RS485 + L x G
Protocol for system interface Suffix
IEC 61850 0
IEC 61850/DNP3 TCP 2
IEC 61850/PROFINET IO
1)
3
IEC 61850/IEC 60870-5-104 4
Protocol 6
1)
only with 100 Mbit Ethernet electrical and multimode
Additional interfaces
Pos. 12
Not equipped 0
A.2
Ordering Information and Accessories
A.2 Ordering Information 7SC803
SIPROTEC Compact, 7SC80, Manual 587
E50417-G1140-C486-A8, Edition 07.2017
