Addr. Parameter C Setting Options Default Setting Comments
1671 67N-TOC-2 Rec. NO
Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
NO 67N-TOC-2 Recloser Curve
1672 67N-TOC-3 ANSI NO
Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
NO 67N-TOC-3 ANSI Curve
1673 67N-TOC-3 Rec. NO
Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
NO 67N-TOC-3 Recloser Curve
1674 67N-TOC-4 ANSI NO
Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
NO 67N-TOC-4 ANSI Curve
Functions
2.3 Directional Overcurrent Protection 67, 67N
SIPROTEC Compact, 7SC80, Manual 145
E50417-G1140-C486-A8, Edition 07.2017
