No. Information Type of
Informa-
tion
Comments
2656 67N OFF OUT 67N/67N-TOC switched OFF
2657 67N BLOCKED OUT 67N/67N-TOC is BLOCKED
2658 67N ACTIVE OUT 67N/67N-TOC is ACTIVE
2659 67N-1 BLOCKED OUT 67N-1 is BLOCKED
2660 67-1 picked up OUT 67-1 picked up
2664 67-1 Time Out OUT 67-1 Time Out
2665 67-1 TRIP OUT 67-1 TRIP
2668 67N-2 BLOCKED OUT 67N-2 is BLOCKED
2669 67-TOC BLOCKED OUT 67-TOC is BLOCKED
2670 67-TOC pickedup OUT 67-TOC picked up
2674 67-TOC Time Out OUT 67-TOC Time Out
2675 67-TOC TRIP OUT 67-TOC TRIP
2676 67-TOC DiskPU OUT 67-TOC disk emulation is ACTIVE
2677 67N-TOC BLOCKED OUT 67N-TOC is BLOCKED
2678 67-3 TRIP OUT 67-3 TRIP
2679 67N-2 TRIP OUT 67N-2 TRIP
2681 67N-1 picked up OUT 67N-1 picked up
2682 67N-1 Time Out OUT 67N-1 Time Out
2683 67N-1 TRIP OUT 67N-1 TRIP
2684 67N-TOCPickedup OUT 67N-TOC picked up
2685 67N-TOC TimeOut OUT 67N-TOC Time Out
2686 67N-TOC TRIP OUT 67N-TOC TRIP
2687 67N-TOC Disk PU OUT 67N-TOC disk emulation is ACTIVE
2691 67/67N pickedup OUT 67/67N picked up
2692 67 A picked up OUT 67/67-TOC Phase A picked up
2693 67 B picked up OUT 67/67-TOC Phase B picked up
2694 67 C picked up OUT 67/67-TOC Phase C picked up
2695 67N picked up OUT 67N/67N-TOC picked up
2696 67/67N TRIP OUT 67/67N TRIP
2697 67-3 picked up OUT 67-3 picked up
2698 67N-3 picked up OUT 67N-3 picked up
2699 67-3 Time Out OUT 67-3 Time Out
2700 67N-3 Time Out OUT 67N-3 Time Out
7559 67-1 InRushPU OUT 67-1 InRush picked up
7560 67N-1 InRushPU OUT 67N-1 InRush picked up
7561 67-TOC InRushPU OUT 67-TOC InRush picked up
7562 67N-TOCInRushPU OUT 67N-TOC InRush picked up
7574 67-3 InRushPU OUT 67-3 InRush picked up
7575 67N-3 InRushPU OUT 67N-3 InRush picked up
31079 >BLK 67-TOC-1 SP >BLOCK 67-TOC-1
31080 67-TOC-1 PU OUT 67-TOC-1 pickedup
31081 67-TOC-1 TRIP OUT 67-TOC-1 TRIP
31082 67-TOC-1 T. O. OUT 67-TOC-1 Time Out
31083 67-TOC-1 BLK OUT 67-TOC-1 is BLOCKED
31084 67-TOC-1 InR.PU OUT 67-TOC-1 InRush picked up
Functions
2.3 Directional Overcurrent Protection 67, 67N
