No. Information Type of
Informa-
tion
Comments
31085 >BLK 67-TOC-2 SP >BLOCK 67-TOC-2
31086 67-TOC-2 PU OUT 67-TOC-2 pickedup
31087 67-TOC-2 TRIP OUT 67-TOC-2 TRIP
31088 67-TOC-2 T. O. OUT 67-TOC-2 Time Out
31089 67-TOC-2 BLK OUT 67-TOC-2 is BLOCKED
31090 67-TOC-2 InR.PU OUT 67-TOC-2 InRush picked up
31091 >BLK 67-TOC-3 SP >BLOCK 67-TOC-3
31092 67-TOC-3 PU OUT 67-TOC-3 pickedup
31093 67-TOC-3 TRIP OUT 67-TOC-3 TRIP
31094 67-TOC-3 T. O. OUT 67-TOC-3 Time Out
31095 67-TOC-3 BLK OUT 67-TOC-3 is BLOCKED
31096 67-TOC-3 InR.PU OUT 67-TOC-3 InRush picked up
31097 >BLK 67-TOC-4 SP >BLOCK 67-TOC-4
31098 67-TOC-4 PU OUT 67-TOC-4 pickedup
31099 67-TOC-4 TRIP OUT 67-TOC-4 TRIP
31100 67-TOC-4 T. O. OUT 67-TOC-4 Time Out
31101 67-TOC-4 BLK OUT 67-TOC-4 is BLOCKED
31102 67-TOC-4 InR.PU OUT 67-TOC-4 InRush picked up
31103 >BLK 67N-TOC-1 SP >BLOCK 67N-TOC-1
31104 67N-TOC-1 PU OUT 67N-TOC-1 picked up
31105 67N-TOC-1 TRIP OUT 67N-TOC-1 TRIP
31106 67N-TOC-1 T. O. OUT 67N-TOC-1 Time Out
31107 67N-TOC-1 BLK OUT 67N-TOC-1 is BLOCKED
31108 67N-TOC-1InR.PU OUT 67N-TOC-1 InRush picked up
31109 >BLK 67N-TOC-2 SP >BLOCK 67N-TOC-2
31110 67N-TOC-2 PU OUT 67N-TOC-2 picked up
31111 67N-TOC-2 TRIP OUT 67N-TOC-2 TRIP
31112 67N-TOC-2 T. O. OUT 67N-TOC-2 Time Out
31113 67N-TOC-2 BLK OUT 67N-TOC-2 is BLOCKED
31114 67N-TOC-2InR.PU OUT 67N-TOC-2 InRush picked up
31115 >BLK 67N-TOC-3 SP >BLOCK 67N-TOC-3
31116 67N-TOC-3 PU OUT 67N-TOC-3 picked up
31117 67N-TOC-3 TRIP OUT 67N-TOC-3 TRIP
31118 67N-TOC-3 T. O. OUT 67N-TOC-3 Time Out
31119 67N-TOC-3 BLK OUT 67N-TOC-3 is BLOCKED
31120 67N-TOC-3InR.PU OUT 67N-TOC-3 InRush picked up
31121 >BLK 67N-TOC-4 SP >BLOCK 67N-TOC-4
31122 67N-TOC-4 PU OUT 67N-TOC-4 picked up
31123 67N-TOC-4 TRIP OUT 67N-TOC-4 TRIP
31124 67N-TOC-4 T. O. OUT 67N-TOC-4 Time Out
31125 67N-TOC-4 BLK OUT 67N-TOC-4 is BLOCKED
31126 67N-TOC-4InR.PU OUT 67N-TOC-4 InRush picked up
31167 67-TOC-1 C. Er. OUT 67-TOC-1 curve multi-selection error
31168 67-TOC-2 C. Er. OUT 67-TOC-2 curve multi-selection error
31169 67-TOC-3 C. Er. OUT 67-TOC-3 curve multi-selection error
Functions
2.3 Directional Overcurrent Protection 67, 67N
SIPROTEC Compact, 7SC80, Manual 149
E50417-G1140-C486-A8, Edition 07.2017
