Addr. Parameter C Setting Options Default Setting Comments
3102 CT Err. I1 1A 0.05 .. 30.00 A 1.00 A Current I1 for CT Angle
Error
5A 0.25 .. 150.00 A 5.00 A
3103 CT Err. F1 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I1
3104 CT Err. I2 1A 0.001 .. 1.600 A 1.000 A Current I2 for CT Angle
Error
5A 0.005 .. 8.000 A 5.000 A
3104 CT Err. I2 1A 0.05 .. 30.00 A 10.00 A Current I2 for CT Angle
Error
5A 0.25 .. 150.00 A 50.00 A
3105 CT Err. F2 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I2
3106 VPH MIN 10 .. 100 V 40 V L-Gnd Voltage of Faulted
Phase Vph Min
3107 VPH MAX 10 .. 100 V 75 V L-Gnd Voltage of Unfaulted
Phase Vph Max
3109 64-1 VGND 1.8 .. 200.0 V; ∞ 40.0 V 64-1 Ground Displacement
Voltage
3110 64-1 VGND 5.0 .. 225.0 V; ∞ 70.0 V 64-1 Ground Displacement
Voltage
3111 T-DELAY Pickup 0.04 .. 320.00 sec; ∞ 1.00 sec Time-DELAY Pickup
3112 64-1 DELAY 0.10 .. 40000.00 sec; ∞ 10.00 sec 64-1 Time Delay
3113 50Ns-2 PICKUP 1A 0.001 .. 1.600 A 0.300 A 50Ns-2 Pickup
5A 0.005 .. 8.000 A 1.500 A
3113 50Ns-2 PICKUP 1A 0.05 .. 30.00 A 10.00 A 50Ns-2 Pickup
5A 0.25 .. 150.00 A 50.00 A
3114 50Ns-2 DELAY 0.00 .. 320.00 sec; ∞ 1.00 sec 50Ns-2 Time Delay
3115 67Ns-2 DIRECT Forward
Reverse
Non-Directional
Forward 67Ns-2 Direction
3117 50Ns-1 PICKUP 1A 0.001 .. 1.600 A 0.100 A 50Ns-1 Pickup
5A 0.005 .. 8.000 A 0.500 A
3117 50Ns-1 PICKUP 1A 0.05 .. 30.00 A 2.00 A 50Ns-1 Pickup
5A 0.25 .. 150.00 A 10.00 A
3118 50Ns-1 DELAY 0.00 .. 320.00 sec; ∞ 2.00 sec 50Ns-1 Time delay
3119 51Ns PICKUP 1A 0.001 .. 1.400 A 0.100 A 51Ns Pickup
5A 0.005 .. 7.000 A 0.500 A
3119 51Ns PICKUP 1A 0.05 .. 4.00 A 1.00 A 51Ns Pickup
5A 0.25 .. 20.00 A 5.00 A
3120 51NsTIME DIAL 0.10 .. 4.00 sec; ∞ 1.00 sec 51Ns Time Dial
3121A 50Ns T DROP-OUT 0.00 .. 60.00 sec 0.00 sec 50Ns Drop-Out Time Delay
3122 67Ns-1 DIRECT. Forward
Reverse
Non-Directional
Forward 67Ns-1 Direction
3123 RELEASE DIRECT. 1A 0.001 .. 1.200 A 0.010 A Release directional element
5A 0.005 .. 6.000 A 0.050 A
3123 RELEASE DIRECT. 1A 0.05 .. 30.00 A 0.50 A Release directional element
5A 0.25 .. 150.00 A 2.50 A
3124 PHI CORRECTION -45.0 .. 45.0 ° 0.0 ° Correction Angle for Dir.
Determination
3125 MEAS. METHOD COS φ
SIN φ
COS φ Measurement method for
Direction
Functions
2.13 Ground Fault Protection 64, 67N(s), 50N(s), 51N(s)
