No. Information Type of
Informa-
tion
Comments
6513 >BLOCK 59 SP >BLOCK 59 overvoltage protection
6530 27 OFF OUT 27 Undervoltage protection switched OFF
6531 27 BLOCKED OUT 27 Undervoltage protection is BLOCKED
6532 27 ACTIVE OUT 27 Undervoltage protection is ACTIVE
6533 27-1 picked up OUT 27-1 Undervoltage picked up
6534 27-1 PU CS OUT 27-1 Undervoltage PICKUP w/curr. superv
6537 27-2 picked up OUT 27-2 Undervoltage picked up
6538 27-2 PU CS OUT 27-2 Undervoltage PICKUP w/curr. superv
6539 27-1 TRIP OUT 27-1 Undervoltage TRIP
6540 27-2 TRIP OUT 27-2 Undervoltage TRIP
6565 59 OFF OUT 59-Overvoltage protection switched OFF
6566 59 BLOCKED OUT 59-Overvoltage protection is BLOCKED
6567 59 ACTIVE OUT 59-Overvoltage protection is ACTIVE
6568 59-1 picked up OUT 59-1 Overvoltage V> picked up
6570 59-1 TRIP OUT 59-1 Overvoltage V> TRIP
6571 59-2 picked up OUT 59-2 Overvoltage V>> picked up
6573 59-2 TRIP OUT 59-2 Overvoltage V>> TRIP
Functions
2.6 Voltage Protection 27, 59
SIPROTEC Compact, 7SC80, Manual 201
E50417-G1140-C486-A8, Edition 07.2017
