Addr. Parameter C Setting Options Default Setting Comments
1522A 67-TOC MEASUR. Fundamental
True RMS
Fundamental 67-TOC measurement of
1523 67-2 Direction Forward
Reverse
Non-Directional
Forward 67-2 Direction
1524 67-1 Direction Forward
Reverse
Non-Directional
Forward 67-1 Direction
1525 67-TOC Direct. Forward
Reverse
Non-Directional
Forward 67-TOC Direction
1526 Recloser Curves Curve A (101)
Curve B (117)
Curve C (133)
Curve D (116)
Curve E (132)
Curve K (162)
Curve N (104)
Curve R (105)
Curve W (138)
Curve 2 (135)
Curve 3 (140)
Curve 8 (113)
Curve 8* (111)
Curve 9 (131)
Curve 11 (141)
Curve A (101) Recloser Curves
1530 67 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
67
1531 MofPU Res T/Tp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> T/Tp
1534 67-3 PICKUP 1A 1.00 .. 30.00 A; ∞ ∞ A 67-3 Pickup
5A 5.00 .. 150.00 A; ∞ ∞ A
1535 67-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67-3 Time Delay
1536 67-3 Direction Forward
Reverse
Non-Directional
Forward 67-3 Direction
1537A 67-3 MEASUREM. Fundamental
True RMS
Fundamental 67-3 measurement of
1538 67-3 w. Inrush NO
YES
NO 67-3 with Inrush Restraint
1539A 67-3 active with 79 active
always
always 67-3 active
1540 67-TOC-1 Dir. Forward
Reverse
Non-Directional
Forward 67-TOC-1 Direction
1541 67-TOC-2 Dir. Forward
Reverse
Non-Directional
Forward 67-TOC-2 Direction
Functions
2.5 Single-Phase Overcurrent Protection
