Addr. Parameter Setting Options Default Setting Comments
7127 DEADTIME 1: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Phase Fault
7128 DEADTIME 1: G 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Ground Fault
7129 DEADTIME 2: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Phase Fault
7130 DEADTIME 2: G 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Ground Fault
7131 DEADTIME 3: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Phase Fault
7132 DEADTIME 3: G 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Ground Fault
7133 DEADTIME 4: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Phase Fault
7134 DEADTIME 4: G 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Ground Fault
7135 # OF RECL. GND 0 .. 9 1 Number of Reclosing Cycles
Ground
7136 # OF RECL. PH 0 .. 9 1 Number of Reclosing Cycles Phase
7137 Cmd.via control (Setting options depend on
configuration)
none Close command via control device
7138 Internal SYNC (Setting options depend on
configuration)
none Internal 25 synchronisation
7139 External SYNC YES
NO
NO External 25 synchronisation
7140 ZONE SEQ.COORD. OFF
ON
OFF ZSC - Zone sequence coordination
7150 50-1 No influence
Starts 79
Stops 79
No influence 50-1
7151 50N-1 No influence
Starts 79
Stops 79
No influence 50N-1
7152 50-2 No influence
Starts 79
Stops 79
No influence 50-2
7153 50N-2 No influence
Starts 79
Stops 79
No influence 50N-2
7154 51 No influence
Starts 79
Stops 79
No influence 51
7155 51N No influence
Starts 79
Stops 79
No influence 51N
7156 67-1 No influence
Starts 79
Stops 79
No influence 67-1
7157 67N-1 No influence
Starts 79
Stops 79
No influence 67N-1
7158 67-2 No influence
Starts 79
Stops 79
No influence 67-2
Functions
2.14 Automatic Reclosing System 79
284 SIPROTEC Compact, 7SC80, Manual
E50417-G1140-C486-A8, Edition 07.2017
