No. Information Type of
Informa-
tion
Comments
6058 79 2ndCycRunPh3 OUT 79 2nd cycle running phase 3
6059 79 3rdCycRunPh1 OUT 79 3rd cycle running phase 1
6060 79 3rdCycRunPh2 OUT 79 3rd cycle running phase 2
6061 79 3rdCycRunPh3 OUT 79 3rd cycle running phase 3
6062 79 4thCycRunPh1 OUT 79 4th or higher cycle running phase 1
6063 79 4thCycRunPh2 OUT 79 4th or higher cycle running phase 2
6064 79 4thCycRunPh3 OUT 79 4th or higher cycle running phase 3
6065 79 BLK:CBOpenP1 OUT 79: CB open with no trip phase 1
6066 79 BLK:CBOpenP2 OUT 79: CB open with no trip phase 2
6067 79 BLK:CBOpenP3 OUT 79: CB open with no trip phase 3
6068 79 TactExpPh1 OUT 79: action time expired before trip ph1
6069 79 TactExpPh2 OUT 79: action time expired before trip ph2
6070 79 TactExpPh3 OUT 79: action time expired before trip ph3
6071 79 MaxNoCycPh1 OUT 79: max. no. of cycles exceeded phase 1
6072 79 MaxNoCycPh2 OUT 79: max. no. of cycles exceeded phase 2
6073 79 MaxNoCycPh3 OUT 79: max. no. of cycles exceeded phase 3
6074 79 DTSD Exp Ph1 OUT 79: Max. Dead Time Start Delay Exp. Ph1
6075 79 DTSD Exp Ph2 OUT 79: Max. Dead Time Start Delay Exp. Ph2
6076 79 DTSD Exp Ph3 OUT 79: Max. Dead Time Start Delay Exp. Ph3
6077 79 Pole Disc. OUT 79 Pole Discrepancy
6078 79 NOTReady Ph1 OUT 79 Auto recloser is NOT ready phase 1
6079 79 NOTReady Ph2 OUT 79 Auto recloser is NOT ready phase 2
6080 79 NOTReady Ph3 OUT 79 Auto recloser is NOT ready phase 3
Functions
2.16 Triple Single Mode
